2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35 1 1/4 Inch

2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35 1 1/4 Inch

    • 2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch
    • 2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch
    • 2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch
    • 2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch
  • 2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: ISO
    Model Number: 2S-350-35

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Pc
    Price: Negotiation
    Packaging Details: Box,Carton
    Delivery Time: 3Days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 6666 Sets per month
    Contact Now
    Detailed Product Description
    Material: Stainless Steel Type: Normal Close
    Port Size: 1 1/4 Inch Connect Ion Method: Threaded

    2/2 Way 2S-350-35 Water Solenoid Valve/ G 1 1/4" Stainless Steel Direct Acting





    Production of solenoid valves, we are professional



    The 2S350-35 solenoid valve body is made of 304# stainless steel, which is durable and suitable for working in harsh environments. Strong anti-oxidation and corrosion resistance. The product is mainly used to control the placement of industrial raw materials. It can also be used to regulate other fluids. Working principle: When energized, the electromagnetic force opens the pilot hole, the pressure in the upper chamber drops rapidly, and a pressure difference between the upper and lower parts is formed around the closing member.





    Technical data

    el code 2S025-06 2S025-08 2S040-10 2S160-10 2S160-15 2S200-20 2S250-25 2S350-35 2S400-40 2S500-50
    Symbol Air.Wter Oil Gas
    Fluid Media Aie,Water,Oil,Gas
    Operating Mode Direct Acting
    Type Normally Vlosed
    Orifice 2.5 4 16 20 25 35 40 50
    Cv Factor 0.23 0.6 4.8 7.6 12 24 29 48
    Pipe Size 1/8” 1/4” 3/8” 3/8” 1/2” 3/4” 1” 11/4” 11/2” 2”
    Viscosity Under20CTS
    Operating Water:0-7 Air:0-7 Oil:0-5
    Fluds Temp -5-80℃
    Available Voltage +-10% AC220V 110V DC24V Contact the factory Others
    Body Material S.S.304(S.S316 Special Made)
    Seals Material NBR or VITON





    Dimension Of 2S350-35 Pneumatic Solneid Valves:

    2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch

    2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch

    2/2 Way Stainless Steel Pneumatic Solenoid Valve 2S-350-35  1 1/4 Inch



    Use maintenance:

    1. It is recommended that the employer assign a person to be responsible for operation and maintenance.



    2. Regular maintenance of 1-2 times a year to make the solenoid valve work reliably and longevity. The following four conditions inside the solenoid valve are the reasons that hinder the normal operation of the solenoid valve and shorten the life.



    3. The medium changes during use



    4. Rusting inside the takeover



    5. The oil of the air compressor is oxidized to produce carbon particles such as tar and mixed into the pipeline.



    6. There are impurities such as dust and dirt in the pipeline.



    7. When the solenoid valve is installed or is put into operation after long-term use, it must pass through the medium and try to operate several times. After working normally, it can be used formally.



    8. When the steam valve is put into operation after a long time of use, the common sense action should be performed several times after the condensate is drained, and it can be used officially after normal operation.



    9. The power must be turned off and the media pressure removed before maintenance.



    10. The coil assembly should not be disassembled



    11. After disassembling and cleaning, all kinds of parts should be restored in order.



    12. After disassembling and cleaning, all kinds of parts should be restored in order.



    please care the products details at our website, any confuse please contact us or Note your request online. Big quantity purchase ,please contact our online service to ask more economic shipping way or discuss the more pretty price.
