Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch

Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch

    • Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch
    • Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch
    • Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch
    • Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch
  • Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: ISO/CE
    Model Number: 2S-160-15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Pc
    Price: Negotiate
    Packaging Details: Box,Carton
    Delivery Time: 5days
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 50000 sets per month
    Contact Now
    Detailed Product Description
    Material: Stainless Steel Pipe Size: 1/2" Inch
    Connection Type: Thread Voltage: AC 220V

    Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2"



    The valve is a two-way valved water inlet solenoid valve, the structure of which is mainly composed of a pilot valve and a main valve, and the main valve adopts a rubber sealing structure.The 2s series normally closed solenoid valve is made of stainless steel and is more durable. Suitable for air, compressed air, water, oil and other media, low noise, high reliability, can work normally in extreme environments.





    Technical data:
    Model 2S030-06 2S050-10 2S160-15 2S200-20 2S-250-25 2S-350-35 2S-500-50
    Working medium Gas,Air,Water,Oil,Steam
    Operating pattern Direct Drive
    Type Normally closed type
    pipe size 1/8” 3/8” 1/2” 3/4” 1” 1 1/4” 2”
    Operation fluid viscosity below 20cst
    Voltage range +- 10 percent
    Temperature -5-80℃



    Dimensions Pohoto:

    Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch





    Model Bore A B C D
    2S030-06 1/8” 68.5 34 78.5 34
    2S050-10 3/8” 80.5 40 94 40
    2S160-15 1/2” 96 57 110 67.5
    2S200-20 3/4 101 57 117 72.5
    2S250-25 1” 106 76 126 98
    2S350-35 1 1/4” 132 86 155 111
    2S400-40 1 1/2” 137 93.5 166.5 120
    2S500-50 2” 149.5 122 182 165







    Detail:

    Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch

    Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch



    Normally Closed Solenoid Pneumatic Valve / Thread Water Solenoid Valve 1/2" Inch







    Inlet water solenoid valve working principle



    When the position is normal, the movable iron core seals the pilot valve port, the pressure in the valve chamber is balanced, and the main valve port is closed. When the coil is energized, electromagnetic force is generated to suck the movable iron core, and the medium in the main valve chamber of the water inlet solenoid valve is leaked from the pilot valve port, so that a pressure difference is generated, the diaphragm or the valve cup is quickly lifted, and the main valve port is opened. The valve is in the path. When the coil is de-energized, the magnetic field disappears, the movable iron core is reset, the pilot valve port is closed, and the pressure in the pilot valve and the main valve chamber is balanced, and the valve is closed again.



    There are closed chambers in the inlet solenoid valve. There are through holes in different positions. Each hole leads to different oil pipes. The middle of the cavity is a valve. On both sides are two electromagnets. Which side of the magnet coil is energized? Which side is attracted to, by controlling the movement of the valve body to block or leak different oil drain holes, and the oil inlet hole is normally open, the hydraulic oil will enter different oil drain pipes, and then pushed by the pressure of the oil The piston of the cylinder, the piston drives the piston rod, and the piston rod drives the mechanical device. This controls the mechanical motion by controlling the current of the electromagnet.





    If you are willing to buy, please contact us, we will provide the best quality products and best service!
