Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem

Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem

  • Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
  • Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
  • Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
  • Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
  • Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem
Product Details:
Place of Origin: Ningbo,China
Brand Name: BRANDO
Certification: CE
Model Number: BAPC313035506
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: negotiation
Packaging Details: standard carton
Delivery Time: 5-8 WORK DAY
Payment Terms: L/C, Western Union, D/P
Supply Ability: 5000PCS PER DAY
Contact Now
Detailed Product Description
Material: SS304 Color: Silvery
Tube OD: 13.0 Application For: Pneumatic
Seal: NBR Technology Using: Weld
High Light:

solenoid valve stem

,

stainless steel valve stems

Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem



Feauture and characteristic



1.Three way two positon normally closed solenoid stem/Plunger tube assembly.This type of solenoid armature has three ports and Two position including the input and the output.

2.This item use mental material-stainless steel/SS304 except the NBR Seal.

SS304: 304 stainless steel is a common stainless steel material, 7.93 g/cm 3 density, also known as 18/8 stainless steel industry. High temperature resistance , with good processing performance, high toughness characteristics, widely used in industrial and furniture decoration industry and food and medical industry.

NBR: has good resistance to mineral oils, vegetable oils, benzene/petrol, ordinary diluted acids and alkaline.

3.With male thread in the top place of armature,connecting the solenoid coil/solenoid coil housing by fitting the thread.

4.Has circular Thread Seat as the connection as well.

5.The plunger and spring is a bit little uncommon.External spring and interior spring coexist,providing enough spring force when de-energized and hold the solenoid stem easily.Plunger shape is different from the common plunger.Except the NBR seal in the top and bottom,there are four grooves and one vent in the surface of the plunger.And  the shape of bottom of the plunger is similar to a fan.



Application and purpose



1.Mainly used for solenoid coil.A part of the solenoid valve/solenoid armature/pneumatic solenoid valve

2,After assembling,The pneumatic solenoid valve controls the movement of the valve body to stop or leak out different oil drainage holes, and the oil intake hole is normally open. Hydraulic oil will enter different oil drainage pipes. And drive the piston cylinder through the pneumatic solenoid valve oil pressures. pneumatic solenoid valve solenoid current control the entire Mechanical movement of solenoid valves when energized



The advantages and disadvantages of pneumatic solenoid valve



1.In vacuum, negative pressure, zero pressure can work normally, but the diameter is generally not more than 25 mm.

2.It can also be operated at zero differential pressure or vacuum or high voltage, but the power is large, so it must be installed horizontally.

3.The upper limit of fluid pressure range is high, and can be installed arbitrarily (to be customized) but must meet the fluid pressure differential conditions.



Know more detail by parameter/dimension



Brand BRANDO
NO. BAPC313035506
tUBE OD

13.0mm

Tube height 35.5mm
Item weight  63g
Pressure  Normal
Temperture Nomal
Related voltage AC/DC
Lead time Within 5 work days



The example of application



Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem 0



The Relate items show



Normally Closed SS304 Solenoid Armature Assembly Application For Pneumatic Solenoid Valve/Solenoid Stem 1



Provide Fast delivery because our factory located in Ningbo-Chinese second largest port city

Guarantee each pieces of items quality.Strict quality control is our diomiant principle

Look forward to yours visit.With any questions and problems,we will make detail instrution for you
