Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector

Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector

    • Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector
    • Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector
  • Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector

    Product Details:

    Place of Origin: China
    Brand Name: OEM
    Certification: CE, ISO
    Model Number: BAZJ043

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pcs
    Price: negotiation
    Packaging Details: Inner box, carton, pallet
    Delivery Time: 7 days after confirmed order
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Part Name: Pulse Jet Valve Voltage: 110 V , 220V AC, 24V DC
    Body Material: Alumininum Valve Type: Normally Close
    Media: Clean Air Application: For Dust Collector



    Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector



    Pulse valve BAZJ043 is designed as a cheap type, the coil is common 0200 type, the diaphragm is white NBR, with high performance of blowing. Hot sale at China market and vietnam market.

    Welcome your any question and enquiry.



    Features:

    1, The diaphragm pulse valves are especially designed for dust collector service applications, combing high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

    2, The high flow, angle type bodies, springless construction, in combination with the special diaphragm assemblies give the unique operating features required for dust collector service applications.

    3, Integral compression fitting for fast, easy, secure installation

    4, Built-in silencers reduce noise and prevent foreign particles from entering the valve

    5, The integral operators are provided with epoxy moulded F-class coils. Various optional waterproof and explosionproof solenoids for use in potentially explosive atmospheres(gas & dust) according to Directive ATEX94/9/EC can be mounted on the same basic valve

    6, The valves satisfy all relevant EC directives.



    Pulse valve internal structure and main parts:

    Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector

    Part No. Part Name Material
    1 Solenoid coil Enamelled copper wire
    2 Armature aseembly 430FR
    3 Small top cap Alumininum ADC
    4 Diaphragm set NBR
    5 Top cap Alumininum ADC
    6 Big spring SS321
    7 Bolts and Nuts SS302
    8 Diaphragm set NBR
    9 Valve body Alumininum ADC



    Diaphragm Pulse Valve Model Specifications:

    Part No. Pipe Size Orifice Size Flow coefficient Kv (m³/h) Flow coefficient Kv (l/min) Operating pressure differential (bar) Min Operating pressure differential (bar) Max
    BAZ043 3/4" 25 14 233 0.3 8.5
    BAZJ043 3/4" 25 14 233 0.3 8.5
    BAZ044 1" 25 23 283 0.3 8.5
    BAZJ044 1" 25 23 283 0.3 8.5
    BAZ047 1.5" 52 46 768 0.3 8.5
    BAZ050 2" 66 77 1290 0.35 8.5
    BAZ051 2.5" 66 92 1540 0.35 8.5
    BAY060 3" 72 170 2833 1 6





    We also sell solenoid coil and armature assmebly as kits for pulse valve:

    Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector

    Economic 24v DC Pneumatic Pulse Valve , Pulse Jet Valves for Dust Collector





    Welcome your any enquiry, pls send your question to email: brandon.bao@brandopneumatic.com
