High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type

High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type

    • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
    • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
    • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
    • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
    • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
  • High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type

    Product Details:

    Place of Origin: Ningbo, China
    Brand Name: BRANDO or OEM
    Certification: CE ISO
    Model Number: DIN 43650B

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: USD0.5 TO 6.0 PER PC
    Packaging Details: Bubble bag, inner box, carton, pallet
    Delivery Time: 15 work days after payment or faster
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 50000cs per fornight
    Contact Now
    Detailed Product Description
    Part Name: Solenoid Coil Connector Material: Plastic,Screw,NBR,stainless Steel
    Color: Light Green Connector Cord Material: Pentagon Black Plastic
    For Use With: 11mm Solenoid Coil Ambient Temperature: Normal



     Magnetic valve part High Precision Plug Lead Type Solenoid Coil Connector



    Solenoid coil connector used for assembling with solenoid coil,we provide a variety of items.For instance:pom fast fitting/quick coupling/fast coupling/plastic fast fitting/pipe adapter/Telescoping pneumatic cylinders/singer acting cylinders/telescoping cylinders/double acting cylinders,etc

    The parameters  can be customized as per our client's demand, no matter the plastic shell or Interior construction ,etc. What's more, our quality serve are guaranteed absolutely with our rich experience in this field. Feel free to contact us and we'll reply you efficiently.



    Shape design analysis

    Transparent color plastic shell,Black plastic connector cord,Diaphragm of stainless steel/NBR,black plastic seat with screw to fix,a screw through the hollow channel,clip,LED.






    Specifications:



    Brand BRANDO
    NO. SB204
    Insulation Class H
    Connector cord material Black plastic
    Approval TUV,UL
    Distance 11mm
    Form 2+1GND
    Protection Class IP65
    Working voltage AC250V DC300V
    Nomical current 10A
    Max condutor Section 3×1.5mm2
    Contact Resistance <=5 mΩ
    Fixing Screw M3×30
    Width 20.5mm
    Height 30.5mm
    length 29mm
    plug width 11mm
    plug length 14.5mm



    Applications of Solenoid coill connector:
    1. Espresso Coffee Machines
    2. Disco Smoke Machines
    3. Carpet Cleaners
    4. Medical Equipment
    5. Vacuum Cleaners
    6. Dental Equipment
    7. lrons
    8. Water Gasifying Equipment
    9. lroning Presses
    10. Vending Mahines
    11. Steam Generators
    12. Air Conditioners
    13. Steam Gleaning Systems
    14. Cooling Systems
    15. snowflake machine
    16. Steam Mop



    Overviewing to see the detail


    High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type





    Items' Overall descriptiom of image :



    High Precision Din Connectors For Solenoid Valves Light Green Color Plug Lead Type
