Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm

Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm

    • Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm
    • Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm
  • Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm

    Product Details:

    Place of Origin: China
    Brand Name: ASCO or OEM
    Certification: CE ISO
    Model Number: 3 inch diaphragm

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: USD0.50 to 20.00 USD PER PC
    Packaging Details: PVC bag, inner box, carton, than packed by pallet; also can be packed by color card and can be customized
    Delivery Time: 5 working days after payment
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Part Name: ASCO 3 Inch Diaphragm Part No.: 3 Inch
    Material: Nitrile NBR Color: Black
    Working Life: More Than 1 Million Cycles Install For Valve Size: 3 Inch Pulse Valve



    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm





    3 inch nitirile diaphragm for asco SCG353.060 pulse valve Quick details:

    1, made of imported high quality Nitril, NBR rubber material, the working life is more than 1 million cylces or more than 3 years

    2, color can be white or black, or customized by you

    3, can install on 3 inch pulse valve

    4, other size can be customized by your drawing or sample



    Detailed specification:

    Model 3" pulse valve diaphragm
    Center distance φ187
    Outer diameter /
    Hole numbers for mounting 8
    Working ambient temperature -20℃ to 80 ℃
    Working pressure 0.2Mpa to 0.8Mpa
    Working medium Clean air
    Life expectancy over 1 million times or 3 yeas



    The diaphragm position in the complete pulse valve:

    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm

    Overall dimension:

    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm

    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm





    More description of diaphragms:



    1, Diaphragm (rubber or fabric reinforcement in rubber diaphragms) is a precision functional part used for checking pressure or changing fluid pressure into driving power

    2, Diaphragm has been widely used in automobiles, controllers, household gas facilities and appliances with form of pressure sensors, actuators, On-Off switchs

    3, Fabric-reinforcements in rubber diaphragms utilize a layer of an engineered fabric material as parts of the diaphragm construction. This layer of fabric give tremendous design felxibity

    4, A very thin-walled diaphragm can withstand high pressures while remaining very flexible and responsive to minior pressure variations

    5, Fabrics made of polyester, nylon and silk ard commonly used for most applications, fabric used for those applications exposed to high temperature. For those applications that require extremely high strength

    6, All types of elastomers, such as nitrile, EPDM, fluorocarbon, neoprene, silicone, fluorosilicone, can be used in the fabric-reinforced diaphragms.

    7, Fabric-reinforced diaphragms offer advantanges of no leakage, no lubrication, no breakaway force, no friction, high strength, functionality over wide pressure ranges, low cost, simple design, versatility



    Diaphragm installed on pulse valve:

    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm



    We also have many other types of diaphragm for valve, welcome your any question.

    And we also can produce as per your drawing or sample, welcome contact us any time.



    Mounted Stainless Steel Orifice Rubber Diaphragm , Valve Replacement Diaphragm
