Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap

Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap

    • Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap
    • Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap
    • Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap
    • Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap
  • Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap

    Product Details:

    Place of Origin: China
    Brand Name: BFEC or OEM
    Certification: CE, ISO
    Model Number: DMF-Z-20

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: negotiation
    Packaging Details: PVC bag, inner box, canton, then packed by pallet
    Delivery Time: One weeek after payment
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000 pcs per month
    Contact Now
    Detailed Product Description
    Part Name: BFEC DMF-Z-20 Pneumatic Pulse Valve Port Size: 3/4 Inch
    Material: Aluminum, SS304, Enamelled Wire Voltage: DC, AC All Available
    Working Pressure: 0.3--0.8Mpa Working Life: More Than 1 Million Times



    Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap





    Dust bag pulse valve is widely used on applications of dust cleaning from iron and steel metallurgy, cement, thermal power, chemical industry, building, etc

    With high function of capacity of dust cleaning.



    Advantages:

    All BFEC pulse valves are available in pneumatic and electric version and in this last case bfec valves has an unique pilot model for the entire range.



    Complete range of high efficiency diaphragms pulse jet valve of 3/4", 1", 1 1/2", 2", 2 1/2", 3"

    The pulse valve has been developed in order to optimize cleaning systems with quick opening and closing

    times that allow to obtain high peak of pressure inside filter elements with a moderate air consumption, ensuring effectiveness and efficiency.



    Port Size: 3/4"

    Type: Z type, 90 degree angle between inlet and outlet, easily for installation air house and blowpipe





    Model Specification:

    Working pressure 0.5 to 7.5bar
    Working medium clean, dry compressed air
    Working condition

    -40 to 100℃, use normal diaphragm

    -30 to 200℃  use high temperature diaphragm

    Working voltage

    AC, 24, 110, 23v/50-60hz, 19VA

    DC, 24v 15w

    Insulation calss F
    Solenoid coil standard IEC335
    Voltage tolerance + - 10%
    Installation of solenoid coil 360degree
    Protection class IP65
    Type Pneumatic or electric control
    Open starting speed 0.023-0.027seconds
    Working life More than 1 million cycles
    Qty of diaphragm 3/4" to 1" is single diaphragm valve, 1 1/2" to 4" is double diaphragm valve
    Note Can install muffler to remove noise, the connecting thread is G3/8"




    BFEC Pulse Valve technical specifications:

    Working Pressure Working medium Voltage Temperature range Air relative humidity Protection class Diaphragm working life
    0.3-0.8MPa clean air 220V AC

    NBR, Nitrile, -40-82℃

    Viton, -29-232℃

    ≤80% IP65 More than 1 million times or more than 2 years
    0.3-0.8MPa clean air 110V AC

    NBR, Nitrile, -40-82℃

    Viton, -29-232℃

    ≤80% IP65 More than 1 million times or more than 2 years
    0.3-0.8MPa clean air 24V AC

    NBR, Nitrile, -40-82℃

    Viton, -29-232℃

    ≤80% IP65 More than 1 million times or more than 2 years
    0.3-0.8MPa clean air 24V DC

    NBR, Nitrile, -40-82℃

    Viton, -29-232℃

    ≤80% IP65 More than 1 million times or more than 2 years


    Overall Dimensions of BFEC DMF-Z-20 pulse jet valve

    Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap

    Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap



    Pulse Valve Internal Structure and Main Parts:

    Part Name Material
    Solenoid coil high quanlity enamelled wire
    Armature assembly SS304, 430FR
    Small common cap ADC aluminum
    Diaphragm  NBR (nitrile, buna-n)
    Top end cap ADC aluminum
    Big spring SS304
    Screws SS302
    Seal NBR, Viton, all can be customized
    Main body ADC aluminum



    Advantages of BFEC pulse valve:

    1, Complete range of high efficiency diaphragms pulse jet valve of 3/4", 1", 1 1/2", 2", 2 1/2", 3"

    2, suitable for all types dust collector







    Welcome your enquiry, we also can OEM pulse valve as per your special demands. You can call us, or email us, we will response at once.

    Chemical Industry 3 / 4 Inch Solenoid Valve DMF-Z-20 With ADC Aluminum Small Cap
