ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301

ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301

    • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301
    • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301
    • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301
    • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301
    • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301
  • ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301

    Product Details:

    Place of Origin: Ningbo, China
    Brand Name: BRANDO
    Certification: CE, ISO
    Model Number: BAPC211037301

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Price: negotiation
    Packaging Details: Inner box, carton, then packed by pallet
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 1million pcs per month
    Contact Now
    Detailed Product Description
    Part Name: Kits Of Solenoid Stem For ASCO Pulse Valve Tube Diameter: 11mm
    Type: 2/2 Armature Plunger Material: 430FR
    Tube Material: SUS304 Application: ASOC SCG353A043 SCG353A044 Pulse Valve



    ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301





    The solenoid stem for asco pulse valve is made of SUS304 and 430FR, with high quality and good function. Can be installed on Pulse valve SCG353A043 and SCG353A044, with the connecting port size 3/4" and 1"



    Plunger and core are made by magnetic stainless steel specially designed for solenoid applications.

    The guide tube is made with brass, stainless steel is possible upon special agreement. The plunger is mormally quipped with NBR rubber seals. Other materials like viton are available upon request. The armature assembly is designed for more than 1 million cycles.



    ASCO SCG353A043 SCG353A044 solenoid stem quick details:

    Part No. BAPC211037301
    Tube Diameter 11.00mm
    Height 37.30mm
    Tube Material 304 stainless steel
    Movable Plunger Material 430FR magnetic iron
    Spring Material SS304
    Seal Material NBR, EPDM, Silicone, Viton, all can be customized
    Type 2 way 2 way
    Working Voltage 12V DC 24V DC, 36V DC, 48V DC, 24V AC, 110V AC, 220V AC
    Weight 40 grams per set
    Packaging 40sets per box, 12boxes per carton, total 480sets per carton
    Carton Volume 0.02cbm
    Delivery Time One week after received payment
    Application ASCO pulse valve
    OEM Yes, can produce as per your drawing or sample



    ASCO SCG353A043 SCG353A044 solenoid stem voerall dimensions:

    ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301



    Could be assembled to ASCO solenoid coil for pulse valve something like:

    ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301



    We have more than 10 years experience in manufacturing solenoid stem plunger set assembly of solenoid valves. Excellent quality control is one of our main principles. Our design, producing and testing are strictly complied with ISO9001 standard. Now our products of solenoid armature assembly are being exported all over the world. We provide OEM service, accept customer label, develop the product with your drawings or samples.If you have any question, contact us, we will be reply with prompt speed.



    How we select material to control the quality of solenoid stem plunger assembly set for solenoid valve:

    1, the static and movable core is made by rustproof and corrosion-resistant material with high magnetoconductivity and low remanence, and it is also durable and quick.

    2, the solenoid valve guide tube is made by H62 copper brass or SS304 stainless steel, and the thickness for selection is at the range of 0.25 t0 2.5mm.

    3, the seat of plunger tube is made by H59 copper or SS304

    4, adopting the laser solder technology makes the products more perfect and safe.

    5, the spring is made by imported stainless steel wire, which has good performance of pressure and restore.

    6, the sealant can be heatproof, oilproof and also can be exclusively applicable to food. All can do according to your requirements.

    7, the specification is including normally open, normally close, and AC DC voltage. If you have any other question just feel free to contact us.



    Pulse solenoid valve can be widely used in industrial field such as cement manufacturing factories for protecting enviroment:

    ASCO SCG353A044 Pulse Valve Stem Stainless Steel 304 430FR BAPC211037301





    Welcome your any question of solenoid valve stem, armature, plunger set, we will response at once, and we also can produce as per your drawing or sample.
