| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | H6S |
| Minimum Order Quantity: | 4pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 10000pcs per month |
| Product Name: | High Pressure Solenoid Valve | Port Size: | 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Thread Type: | G, NPT | Orifice Size: | 15mm, 20mm, 25mm |
| Body Material: | Stainless Steel 304 | Seal Material: | NBR, FKM, PTFE |
| Working Temperature: | NBR (-10 To +80℃), FKM (-10 To +150℃), PTFE (-20 To +180℃) | Working Media: | Air, Water, Gas, Liquid, Light Oil, Etc |
| Max Working Pressure: | 75 Bar | Operation: | Piston Pilot Operated |
| Function: | 2/2 Way Normally Closed | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | 75 bar High Pressure Solenoid Valve,Stainless Steel High Pressure Solenoid Valve,Water High Pressure Solenoid Valve |
||
75 bar High Pressure Stainless Steel Water Solenoid Valve 3/8'' 1/2'' 3/4'' 1'' 24V 220V
Product Features:
1. Working Medium: Water, Air, Gas, Oil, Liquid, etc
2. Working Temperature: NBR (-5 to +80ºC), FKM (-10 to +150ºC), PTFE (-20 to +180ºC)
3. Max Working Pressure: 75 bar
4. Body Material: Stainless Steel 304
5. Seal Material: NBR, FKM, PTFE
6. Port Size: 3/8'', 1/2'', 3/4'', 1''
7. Orifice Size: 15mm, 20mm, 25mm
8. Function: 2 Way Normally Closed
9. Operation: Pilot Piston Operated
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data:
|
Model No
|
Port
|
Orifice
|
CV
|
Min Pressure
(bar)
|
Max Pressure
(bar)
|
Body
|
Seal
|
Function
|
|
|
AC
|
DC
|
||||||||
|
H6S15B03
|
3/8''
|
15mm
|
4.2
|
1
|
75
|
55
|
SS304
|
NBR
FKM
PTFE
|
2 Way NC
|
|
H6S15B04
|
1/2''
|
15mm
|
4.2
|
75
|
55
|
||||
|
H6S20B06
|
3/4''
|
20mm
|
7
|
65
|
50
|
||||
|
H6S25B25
|
1''
|
25mm
|
11
|
55
|
45
|
||||
Main Dimension:
|
Model No
|
Port
|
A
|
B
|
C
|
|
H6S15B03
|
3/8''
|
75
|
52
|
130
|
|
H6S15B04
|
1/2''
|
75
|
52
|
130
|
|
H6S20B06
|
3/4''
|
85
|
60
|
141
|
|
H6S25B25
|
1''
|
100
|
70
|
148
|
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.
Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
