| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | RCA20DD |
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 5000pcs per month |
| Product Name: | Pulse Valve | Structure: | Dresser Nut |
|---|---|---|---|
| Remote Pilot Size: | 1/8'' | Port Size: | 3/4'' |
| Body Material: | Aluminum (diecast) | Diaphragm Material: | NBR |
| Working Temperature: | -5 To +80℃ | Working Pressure Range: | 5 To 125 Psi |
| High Light: | Pulse Valve RCA20DD,Dresser Nut Pulse Valve,Remote Pilot Pulse Valve |
||
RCA20DD 3/4'' Goyen Type Dresser Nut Remote Pilot Pulse Valve For Dust Collector
Pulse Jet Valve, also called pulse diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the pulse controller. Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Different designs of pulse jet valves:
1. Right Angle Type
2. Embedded Type
3. Fixed Nut Type
4. Straight Through Type
5. Flanged Type
RCA20DD Dimension:
Technical Data:
|
Integral Pilot Model No
|
CA20DD
|
CA25DD
|
CA45DD
|
|
Remote Pilot Model No
|
RCA20DD
|
RCA25DD
|
RCA45DD
|
|
Port Size
|
3/4''
|
1''
|
1 1/2''
|
|
Pilot Size
|
1/8'', 1/4''
|
||
|
Pipe Connection
|
Dresser Nut
|
||
|
Diaphragm Number
|
1
|
2
|
|
|
Working Pressure
|
5 to 125 psi
|
||
|
Diaphragm Material
|
NBR (standard)
FKM (optional) |
||
|
Body Material
|
Aluminum (diecast)
|
||
|
Voltage
|
24VDC, 24VAC, 110VAC, 220VAC
|
||
Our Production:
Related Products:
|
|
|
|
| Fitting | Diaphragm | Remote Pilot Box | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
