DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector

DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector

  • DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector
  • DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector
DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector
Product Details:
Place of Origin: China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: DMF-T-25S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Valve Valve Design: Straight Through, Threaded Port
Port Size: 1'' Diaphragm Material: NBR, FKM
Voltage: 24VDC, 110VAC, 220VAC Working Pressure Range: 0.1 To 0.8 MPa
High Light:

DMF-T-25S Pulse Jet Valve

,

Straight Through Pulse Jet Valve

,

BFEC DMF-T-25S Diaphragm Valve

DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector





Products Description

DMF-Z / MF-Z type Solenoid Pulse Jet valves

DMF-Z-25 type SBFEC right angle solenoid pulse jet valve. It is 1inc port size.
Normal is G thread, NPT thread is also available.

SBFEC right angle solenoid pulse jet valve, DMF Series is solenoid control pulse jet valves, MF series is air control pulse jet valves, & we have two types right angle thread type & submerged type, with different connection from 20mm~102mm, 3/4" ~4".
It is 2-way dust collector valve used for pulsing large volumes of air into filter bags for particulate removal.

Suitable for :
Dust collector applications, in particular for reverse pulse jet filter cleaning including bag filters, cartridge filters, envelope filters, ceramic filters, and sintered metal fibre filters.
Ordering Code
DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector 0
Main Dimension
DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector 1
DMF-T-25S
Technical Data
Integral Pilot
DMF-T-20
DMF-T-25S
DMF-T-40S
DMF-T-50S
DMF-T-62S
Remote Pilot
MF-T-20
MF-T-25S
MF-T-40S


MF-T-50S
MF-T-62S
Port Size
3/4''
1''
1 1/2''
2''
2 1/2''
Diaphragm Number
1
2
Diaphragm Material
NBR, FKM
Body Material
Aluminum Alloy
Pressure Range
0.1 to 0.8 MPa
Voltage
24VDC, 24VAC, 110VAC, 220VAC

Pulse Valve Series
DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector 2
Our Production
DMF-T-25S 1'' Straight Through BFEC Pulse Jet Valve For Dust Collector 3





Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
