Name: 2W200-20-NO 3/4'' 2 Way Normal Open Solenoid Valve 24V 220V
Brand: Brando
SKU: 2W200-20-NO
Rating: 4.5 (194 reviews)

Home Products Brass Solenoid Valve

2W200-20-NO 3/4'' 2 Way Normal Open Solenoid Valve 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2W200-20-NO

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	3/4''	Orifice Size:	20mm
Operation Mode:	2 Way, Normally Open	Action:	Direct Lifting Diaphragm
Working Fluids:	Air, Water, Oil, Gas	Body Material:	Brass
Seal Material:	NBR	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0 To 1 MPa	Temperature Range:	-5 To +80 ℃
High Light:	24V Normal Open Solenoid Valve , 2W200-20-NO Normal Open Solenoid Valve , 2W200-20 Normally Open

2W200-20-NO 3/4'' 2 Way Normal Open Solenoid Valve 24V 220V

This 2W200-20-NO solenoid valve is a two-way, semi-direct lift valve with a normally open operating position. This means that there are two ports in which media flows and the valve will close when the coil is energized to stop media from passing through. Removing the energy from the valve coil will open it and continue the flow. It works across various media such as hot water, air, gas, diesel fuel, Freon, weak acids and weak alkali. The valve features a heavy duty, solid brass body that’s sure to last in the most strenuous projects.

Main Dimension of Solenoid Valve:

2W200-20-NO 3/4'' 2 Way Normal Open Solenoid Valve 24V 220V 0

Model	Port Size	A	B	C
2W160-10	3/8''	66	56	103
2W160-10-NO				125
2W160-15	1/2''	66	56	103
2W160-15-NO				125
2W200-20	3/4''	73	56	110
2W200-20-NO				132
2W250-25	1''	98	73	117
2W250-25-NO				139
2W350-35	1 1/4''	118	93	160
2W350-35-NO				180
2W400-40	1 1/2''	118	93	160
2W400-40-NO				180
2W500-50	2''	156	124	188
2W500-50-NO				209

Technical Data of Solenoid Valve:

Model	2W160-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
Model	2W160-10-NO	2W160-15-NO	2W200-20-NO	2W250-25-NO	2W350-35-NO	2W400-40-NO	2W500-50-NO
Port Size	3/8''	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	16		20	25	35	40	50
Cv Value	4.8		4.8	12	24	29	48
Medium	Air, Water, Oil, Gas
Action	Direct Lifting Diaphragm
Function	2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity	20 cst Below
Pressure	Air: (1 to 1MPa), Water (0 to 0.7MPa), Oil (0 to 0.9MPa), Normally Open (0 to 0.8MPa)
Temperature	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material	Brass
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type	Waterproof Coil, Round Coil, Square Coil, etc.
