Name: 2W160-15 1/2'' Normally Close Brass Solenoid Valve 24V 220V
Brand: Brando
SKU: 2W160-15
Rating: 4.8 (111 reviews)

Home Products Brass Solenoid Valve

2W160-15 1/2'' Normally Close Brass Solenoid Valve 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2W160-15

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1/2''	Orifice Size:	16mm
Operation Mode:	2 Way, Normally Closed	Action:	Direct Lifting Diaphragm
Working Fluids:	Air, Water, Oil, Gas	Body Material:	Brass
Seal Material:	NBR	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0 To 1 MPa	Temperature Range:	-5 To +80 ℃
High Light:	2W160-15 Brass Solenoid Valve , 220V Brass Solenoid Valve , 2W160-15 Water Solenoid Valve

2W160-15 1/2'' Normally Close Brass Solenoid Valve 24V 220V

A water solenoid valve is designed specifically for water media applications. The valves in this category have a brass housing, an NBR seal and are normally closed (NC). These materials are a good and reliable solution for water applications. A solenoid valve acts very quickly in comparison to other valve types.

Design
A solenoid valve is electrically controlled, 2 way 2 position, normally closed (NC). This means that when no power is applied, the valve is in the closed position not allowing water to flow through. When the valve is supplied the proper voltage, it opens to allow water to flow through. These valves are 2/2-way, meaning they have 1 inlet and 1 outlet.

Main Dimension of Solenoid Valve:

2W160-15 1/2'' Normally Close Brass Solenoid Valve 24V 220V 0

Model	Port Size	A	B	C
2W160-10	3/8''	66	56	103
2W160-10-NO				125
2W160-15	1/2''	66	56	103
2W160-15-NO				125
2W200-20	3/4''	73	56	110
2W200-20-NO				132
2W250-25	1''	98	73	117
2W250-25-NO				139
2W350-35	1 1/4''	118	93	160
2W350-35-NO				180
2W400-40	1 1/2''	118	93	160
2W400-40-NO				180
2W500-50	2''	156	124	188
2W500-50-NO				209

Technical Data of Solenoid Valve:

Model	2W160-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
Model	2W160-10-NO	2W160-15-NO	2W200-20-NO	2W250-25-NO	2W350-35-NO	2W400-40-NO	2W500-50-NO
Port Size	3/8''	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	16		20	25	35	40	50
Cv Value	4.8		4.8	12	24	29	48
Medium	Air, Water, Oil, Gas
Action	Direct Lifting Diaphragm
Function	2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity	20 cst Below
Pressure	Air: (1 to 1MPa), Water (0 to 0.7MPa), Oil (0 to 0.9MPa), Normally Open (0 to 0.8MPa)
Temperature	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material	Brass
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type	Waterproof Coil, Round Coil, Square Coil, etc.
