2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	DMF-T-62S

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4 to 7 days
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	10000 pcs per month

Contact Now

Detailed Product Description

Port Size:	2.5''	Valve Type:	Straight Through
Valve Operation:	Diaphragm Pilot Operated	Diaphragm Material:	NBR, FKM
Coil Voltages:	24VAC, 24VDC, 110VAC, 220VAC	Working Pressure Range:	0.1 To 0.8 MPa
High Light:	Straight Through Solenoid Pulse Valve , SBFEC Dust Removal , 2.5'' DMF-T-62S Pulse Valve

2.5'' DMF-T-62S SBFEC Type Straight Through Pulse Valve For Dust Removal

Products Description

Pulse Jet valves are also called as dust collector. They are indirect type solenoid valves. When the solenoid of pulse jet valves gets energized, air trapped in the diaphragm is exhausted causing pressure difference in the diaphragm. Then the diaphragm is suddenly opened. When it is de-energized, air passes through the hole to the chamber which can balance the air pressure and close the valve. The opening and closing of the valve are done very fast for filter cleaning and consumption of compressed air effectively. Moving parts of the valve are kept small for minimum inertia but KV values are very high. Dust collector systems are very useful for removing solid pollutants or recovering valuables from exhaust gases before discharging them to the atmosphere.

Different pulse jet valve structure:

1. Right Angle Type

2. Fixed Nut Type

3. Embedded Type

4. Flanged Type

5. Straight Through Type

Ordering Code

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal 0

Main Dimension

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal 1

DMF-T-62S

Technical Data

Model Number	DMF-T-20	DMF-T-25S	DMF-T-40S	DMF-T-50S	DMF-T-62S
Port Size	3/4''	1''	1 1/2''	2''	2 1/2''
Diaphragm Number	1	2
Diaphragm Material	NBR, FKM
Body Material	Aluminum Alloy
Pressure Range	0.1 to 0.8 MPa
Voltage	24VDC, 24VAC, 110VAC, 220VAC

Pulse Valve Series

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal 2

Our Production

2.5'' DMF-T-62S SBFEC Type Straight Through Solenoid Pulse Valve For Dust Removal 3

More BFEC Pulse Valves for you to choose:


Right Angle Type	Quick Mount Type	Straight Through Type	Submerged Type

Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
