CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector

CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector

  • CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector
  • CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: CA25DD
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 100000 pieces per month
Contact Now
Detailed Product Description
Port Size: 1'' Valve Series: DD
Valve Structure: Right Angle, Dresser Nut Diaphragm Material: NBR, FKM
Working Pressure Range: 0.35 To 0.85 MPa Coil Voltage: 24VDC, 24VAC, 110VAC, 220VAC
Structure: Diaphragm Body Material: Aluminum (Diecast)
Power: Solenoid Application: Dust Collector
High Light:

Dust Collector Goyen Pulse Jet Valve

,

Pulse Jet Valve DD Series

,

1" Pulse Jet Valve

CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector



Products Description
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. CA25DD type pulse valve, which is compression fitting pipe version, there are fixed nut at both ends which make it easy to install and use the valve.
It is also right angle with the 90o angle between the inlet and outlet, & solenoid control, 2-way dust collector valve used for pulsing large volumes of air into filter bags for particulate removal.

Ordering Code
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector 0
Main Dimension
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector 1
CA25DD
Technical Data
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector 2
Integral Pilot Type
CA20DD
CA25DD
CA45DD
Remote Pilot Type
RCA20DD
RCA25DD
RCA45DD
Port Size
3/4''
1''
1 1/2''
Pilot Size
1/8'', 1/4''
Pipe Connection
Dresser Nut
Diaphragm Number
1
2
Working Pressure Range
5 to 125 psi
Diaphragm Material
NBR, FKM
Body Material
Aluminum (diecast)
Voltage
24VDC, 24VAC, 110VAC, 220VAC
Pulse Valve Series
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector 3
Our Production
CA25DD 1" Goyen Type DD Series Pulse Jet Valve For Dust Collector 4





Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
