| Place of Origin: | China |
| Brand Name: | BRANDO |
| Certification: | CE |
| Model Number: | CA20T |
| Minimum Order Quantity: | 2 Pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Boxes,Carton,Pallet |
| Delivery Time: | 4 to 7 days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 10000pcs per month |
| Product Name: | Pulse Jet Valve | Port Size: | 3/4 Inch |
|---|---|---|---|
| Design: | Right Angle, Threaded Port | Diaphragm Material: | NBR, FKM |
| Working Pressure Range: | 0.35 To 0.85 MPa | Coil Voltage: | 24V DC, 24V AC, 110V AC, 220V AC |
| Body Material: | Aluminum (diecast) | Structure: | Diaphragm |
| Power: | Solenoid | Application: | Cartridge Filters, Envelope Filters, Ceramic Filters, Sintered Metal Fiber Filters |
| High Light: | Pulse Jet Valve 3/4'',Pulse Jet Valve CA20T,Dust Collector Goyen Pulse Valve |
||
3/4'' CA20T Goyen Type Pulse Jet Valve For Dust Collector
This is CA20T Goyen Type Pulse Jet Valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse. 24V DC, 24V AC, 110V AC, 220V AC (50/60Hz) voltages for you to choose and other voltages can be customized.
Pulse jet valve is the actuator and key components of the pulse jet cleaning device. It is mainly divided into three types: right angle type, submerged type and straight type. The electromagnetic pulse valve is the compressed air "switch" of the pulse bag type dust collector cleaning system.
Contact Person: Brandon
Tel: +8613454729544
