| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | D76B |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Diaphragm | Suitable Pulse Valve Model: | DMF-YB-76S, MF-YB-76S |
|---|---|---|---|
| Diaphragm Material: | NBR, FKM | 1 Set: | 1pc Big Diaphragm, 1pc Small Diaphragm, 2pcs Springs |
| High Light: | DMF-YB-76S Pulse Valve Diaphragm,MF-YB-76S Pulse Valve Diaphragm,BFEC Pulse Jet Valve Membrane |
||
Diaphragm For DMF-YB-76S MF-YB-76S BFEC Pulse Jet Valve Repair Kit
The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Ordering Code of Diaphragm For SBFEC Pulse Valve:
|
Diaphragm For New Version BFEC Pulse Valves
|
|||
|
Diaphragm
|
Integral Pilot
Pulse Valve
|
Remote Pilot
Pulse Valve
|
Diaphragm Material
|
|
DTY
(Secondary Diaphragm)
|
/
|
/
|
NBR, FKM
|
|
D20
|
DMF-Z-20
|
MF-Z-20
|
|
|
DMF-ZM-20
|
MF-ZM-20
|
||
|
DZL-B
|
DMF-ZL-B
|
MF-ZL-B
|
|
|
D25
|
DMF-Z-25
|
MF-Z-25
|
|
|
DMF-ZM-25
|
MF-ZM-25
|
||
|
DMF-Y-25
|
MF-Y-25
|
||
|
DMF-ZF-25
|
MF-ZF-25
|
||
|
DMF-T-20
|
MF-T-20
|
||
|
D40
|
DMF-Z-40S
|
MF-Z-40S
|
|
|
DMF-Y-40S
|
MF-Y-40S
|
||
|
DMF-ZF-40S
|
MF-ZF-40S
|
||
|
DMF-ZM-40S
|
MF-ZM-40S
|
||
|
DMF-T-25S
|
MF-T-25S
|
||
|
D50
|
DMF-Z-50S
|
MF-Z-50S
|
|
|
DMF-Y-50S
|
MF-Y-50S
|
||
|
DMF-T-50S
|
MF-T-50S
|
||
|
D62
|
DMF-Z-62S
|
MF-Z-62S
|
|
|
DMF-Y-62S
|
MF-Y-62S
|
||
|
D76
|
DMF-Z-76S
|
MF-Z-76S
|
|
|
DMF-Y-76S
|
MF-Y-76S
|
||
|
DMF-T-62S
|
MF-T-62S
|
||
|
D76A
|
DMF-YA-76S
|
MF-YA-76S
|
|
|
D76B
|
DMF-YB-76S
|
MF-YB-76S
|
|
|
D102
|
DMF-Z-102S
|
MF-Z-102S
|
|
|
DMF-Y-102S
|
MF-Y-102S
|
||
|
D102A
|
DMF-Y-102SA
|
MF-Y-102SA
|
|
|
D102E
|
DMF-Y-102SE
|
MF-Y-102SE
|
|
|
Diaphragm For Old Version BFEC Pulse Valves
|
|||
|
LD50
|
DMF-Z-50S
DMF-Y-50S
DMF-T-50S
|
MF-Z-50S
MF-Y-50S MF-T-50S |
NBR, FKM
|
|
LD62
|
DMF-Z-62S
DMF-Y-62S
|
MF-Z-62S
MF-Y-62S |
|
|
LD76
|
DMF-Z-76S
DMF-Y-76S DMF-T-62S
|
MF-Z-76S
MF-Y-76S MF-T-62S
|
|
Dimension of D76B Diaphragm:
 |
|
| Main Diaphragm | Secondary Diaphragm |
Pulse Valve Diaphragm Production Pictures:
