| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 4V410-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Pneumatic Solenoid Valve | Type: | 5/2 Way |
|---|---|---|---|
| Port Size: | In=Out=Exhaust=1/2'' | Pressure Range: | 0.15 To 0.8 MPa (21 To 114 Psi) |
| Max Pressure Resistance: | 1.5 MPa (215 Psi) | Body Material: | Aluminum Alloy |
| Coil Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Working Fluid: | Air (to Be Filtered By 40 μm Filter Element) |
| High Light: | Single Coil Pneumatic Solenoid Valve,Air Control Solenoid Valve 5/2 Way,Airtac 4V410-15 Pneumatic Solenoid Valve |
||
4V410-15 Airtac Type 5/2 Way Air Control Single Pneumatic Solenoid Valve 24V 220V
This 4V410-15 solenoid valve is a 5/2 way pneumatic valve which means it has 5 ports; 2 exhaust ports through which air is regulated as it flows out, 2 power ports that power the system, 1 supply port for the inlet of air pressure, and 2 flow positions. This valve is made with an aluminum alloy and has an aperture of 1/2''.
BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.
Technical Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air (to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal Pilot or External Pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 Way 2 Position
|
5 Way 3 Position
|
|||
|
Operating Pressure
|
0.15~0.8 MPa (21~114 psi)
|
||||
|
Proof
|
1.5 MPa (215 psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum Alloy
|
||||
|
Max. Frequency
|
3cycle/sec
|
||||
Dimension of 4V410-15 Pneumatic Solenoid Valve:
Product video of 4V410-15 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
More Pneumatic Products for you to choose:
Solenoid Operator Manifold Silencer Pneumatic Hose Fittings
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
