Name: PUT Union Tee Push On Quick Connect Pneumatic Hose Fitting 4mm 6mm 8mm 10mm 12mm
Brand: BRANDO
SKU: PUT
Rating: 4.9 (130 reviews)

Home Products Pneumatic Hose Fittings

PUT Union Tee Push On Quick Connect Pneumatic Hose Fitting 4mm 6mm 8mm 10mm 12mm

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	PUT

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Plastic bag, Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	10000000pcs per month

Contact Now

Detailed Product Description

Product Name:	Pneumatic Hose Fittings	Type:	Union Tee
Tube OD (Mertric):	4mm, 6mm, 8mm, 10mm, 12mm	Material:	Plastic
Working Pressure Range:	0 To 0.8 MPa	Working Temperature Range:	0 To +60℃
High Light:	PUT Pneumatic Hose Fitting , Push On Pneumatic Hose Fitting , Pneumatic Tube Connector 8mm

PUT Union Tee Push On Quick Connect Pneumatic Hose Fitting 4mm 6mm 8mm 10mm 12mm

Push-in fittings are so defined as they allow to connect the tube to the fitting in a “instantaneous” way without using tools. The tightness of the tube takes place through an elastic clamp which holds the tube on the external diameter and releases it by pushing the suitable puller. This type of fittings is used in order to speed up the assembly phases mainly in reduced space and time-saving during connection of different pneumatic components.

BRANDO’s push to connect fittings (or push-in fittings) are a quick and convenient method of connecting components in a pneumatic system. Designed for use with polyurethane, polyethylene, and nylon tubing, our composite push-in fittings are available in a variety of sizes to accommodate tubing ranging from 1/8 inch OD to 1/2 inch OD. Numerous configurations are available to meet your connection requirements.

Technical data of Pneumatic Hose Fittings:

Material	Plastic / Brass
Threaded Connection	BSP
	BSPP
	Metric Thread
	NPT
Working Pressure	0 to 0.8MPa
Connecting Tube	PA
Connecting Tube	PU
Connecting Diameter Tube	3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium	Compressed Air
Working Temperature	~60℃

Specifications of PUT Union Tee Pneumatic Hose Fittings:

PUT Union Tee Push On Quick Connect Pneumatic Hose Fitting 4mm 6mm 8mm 10mm 12mm 0

Model No	φD	φD1	L
PUT4	4	11	19
PUT6	6	13	20
PUT8	8	14	23
PUT10	10	18	27
PUT12	12	21	30

List of All Push To Connect Pneumatic Hose Fittings:

PL Male 90 Degree Elbow Pneumatic Hose Fittings 1/8'' 1/4'' 3/8'' 1/2'' 1

Choosing the Right Fittings for Your Pneumatic System:

Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
