| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 5404 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 50000 pcs per month |
| Port Size: | 3/4'', 1'' | Orifice Size: | 20mm, 25mm |
|---|---|---|---|
| Function: | 2 Way, Normally Closed | Operation: | Servo-Assisted Piston |
| Body Material: | Brass | Seal Material: | PTFE + FKM |
| Pressure Range: | 1 To 40 Bar | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | Solenoid Valve 5404 A 20.0 EF,Solenoid Valve 5404 A 25.0 EF,25 bar High Pressure Solenoid Valve |
||
3/4'' 1'' 25 bar High Pressure Brass Solenoid Valve 5404 A 20.0 25.0 EF EB MS 24V 230V
5404 is a servo-assisted piston valve available in Normally Closed and Normally Open versions. It has a piston to seal the valve, instead of a flexible rubber membrane. This robust design allows for high working pressures up to 40 bar. The port sizes range from 1/4" to 1". The dimensions of the orifice range from DN 13 to DN 25. A popular application for the 5404 valve is as a relief valve for compressors. A minimum differential pressure is required for the valve switching function. The solenoid coils are moulded with high-quality epoxy resin. In combination with a plug to DIN 43650 Form A, the valves satisfy degree of protection IP65.
Technical Data of 5404 Solenoid Valve:
| Model No |
Port Size (inch) |
Orifice Size (mm) |
Kv Value (m³/h) |
Pressure Range (bar) |
Body Material | Seal Material | Coil Voltage | Dimension | ||
| A | F | K | ||||||||
| 2 Way Normally Closed, Servo-Assisted Piston | ||||||||||
| 5404 | 1/4'' | 13 | 1.7 | 1 to 50 bar | Brass | PTFE+FKM |
12VDC 24VDC 24VAC 110VAC 220VAC |
72 | 32 | 97/106 |
| 3/8'' | 13 | 1.7 | 72 | 32 | 97/106 | |||||
| 1/2'' | 13 | 1.7 | 72 | 32 | 97/106 | |||||
| 3/4'' | 20 | 7 | 1 to 40 bar | 92 | 60 | 128 | ||||
| 3/4'' | 25 | 11 | 92 | 60 | 128 | |||||
| 1'' | 25 | 11 | 92 | 60 | 128 | |||||
| 2 Way Normally Open, Servo-Assisted Piston | ||||||||||
| 5404-NO | 1/4'' | 13 | 1.7 | 1 to 40 bar | Brass | PTFE+FKM |
12VDC 24VDC 24VAC 110VAC 220VAC |
72 | 32 | 103 |
| 3/8'' | 13 | 1.7 | 72 | 32 | 103 | |||||
| 1/2'' | 13 | 1.7 | 72 | 32 | 103 | |||||
BRANDO Solenoid Valve Production Video:
More High Pressure Solenoid Valves for you to choose:
| Brass Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 50 bar |
|
|
|
|
| MAX 50 bar | MAX 70 bar | MAX 120 bar | MAX 200 bar |
| Stainless Steel Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 100 bar |
|
|
|
|
| MAX 120 bar | MAX 160 bar | MAX 200 bar | MAX 300 bar |
