Name: 1'' DN25 PN16 Pneumatic Angle Seat Piston Valve With Air Actuated
Brand: Brando
SKU: JZF-DN25-SS
Rating: 4.6 (161 reviews)

Home Products Pneumatic Cylinder Valve

1'' DN25 PN16 Pneumatic Angle Seat Piston Valve With Air Actuated

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	JZF-DN25-SS

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1''	Port Connections:	Threaded
Orifice Size:	25mm	Working Fluids:	Netral And Aggressive Liquid, Gas
Body Material:	SS304, SS316	Seal Material:	PTFE
Working Pressure Range:	0.4 To 0.8 MPa	Max. Working Pressure Range:	1.6 MPa
High Light:	1'' Angle Seat Piston Valve , DN25 Angle Seat Piston Valve , Y-Type Pneumatic Angle Seat Valve

1'' DN25 PN16 Pneumatic Angle Seat Piston Valve With Air Actuated

Pneumatic angle seat valve is a general switch in the automatic control system which are suitable in demanding applications such as steam, water and aggressive media. They are especially suited for vacuum and fast acting applications that require a long service life. It is widely used in printing, dyeing, bleaching, food, washing, chemical, water treatment, pharmacy and other automatic machinery and equipment. It is featured with water hammer protection, noise-free, reliable sealing performance.

Main Dimension of Angle Seat Valve:

Stainless Steel Body With Stainless Steel Actuator

1 1/4'' Threaded 2/2 Way Pneumatic Angle Seat Valve Double Acting 0

Nominal Diameter	Actuator (mm)	D	R	P	G	H	L	L1	T
DN15	50	62	33.5	1/8''	1/2''	126	137	68	13
DN20	50	62	33.5		3/4''	138	144	75	16
DN25	50	62	33.5		1''	148	156	90	16
DN32	63	76	42		1 1/4''	182	188	110	21
DN40	63	76	42		1 1/2''	182	190	116	21
DN50	63	76	42		2''	195	205	136	22
DN65	80	96	52		2 1/2''	280	252	185	30
DN80	100	114	63		3''	320	280	220	33
DN100	100	114	63		4''	350	300	235	35

Technical Data of Angle Seat Valve:

Medium Temperature	-10 to +180℃
Ambient Temperature	-10 to +60℃
Max. Working Pressure Range	1.6 MPa
Working Medium	Netral and Aggressive Liquid, Gas
Working Pressure	0.4 to 0.8 MPa
Body Material	SS304, SS316
Seal Material	PTFE
Connection Size	1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 2-1/2'', 3'', 4''
Port Connections	Threaded, Flanged, Welded, Clamp
Nominal Diameter	DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100
Safety setting in case of power failure	Normally Closed, Normally Open
