Name: 1'' Flanged PTFE Solenoid Valve Anti Corrosive DC24V AC220V
Brand: Brando
SKU: PTFE-25F
Rating: 4.5 (163 reviews)

Home Products Plastic Solenoid Valve

1'' Flanged PTFE Solenoid Valve Anti Corrosive DC24V AC220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	PTFE-25F

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Anti Corrosion Solenoid Valve	Function:	2 Way, Normally Closed
Port Size:	1''	Orifice Size:	25mm
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Fluids:	Acid & Alkali (Gas, Liquid)
Valve Body Material:	PTFE ()	Seal Material:	FKM, EPDM
Working Pressure Range:	0.01 To 0.6 MPa
High Light:	1'' PTFE Solenoid Valve , Flanged PTFE Solenoid Valve , Anti Corrosive Flanged Valve

1'' Flanged PTFE Solenoid Valve Anti Corrosive DC24V AC220V

Outstanding Chemicals Resistance:

1. PTFE is always stable almost for any chemicals such as strong acid (98% H2SO4), HNO3, HCL and its weights and performance has no any change even if it is boiled in the aqua fortis.

2. PTFE has the properties of no damping and FR as well as it is also stable for oxidant and UV light, therefore it is climate resistance, anti-oxidant, anti-stain and fragilization resistance.

3. No pollution, no toxic, no odor, high purities and chemical inerthness, it will have no any effect on the fluid medium. 4. Wide Temperature application range: -50℃~+200℃.

Technical Data of Body Solenoid Valve:

Model		PTFE-15	PTFE-20	PTFE-25	PTFE-32	PTFE-40	PTFE-50	PTFE-65
Port Size		1/2''	3/4''	1''	1 1/4''	1 1/2''	2''	2 1/2''
Orifice Size		15mm	20mm	25mm	32mm	40mm	50mm	60mm
Cv Value		4	5.5	13	17	25	40	62
Medium		Weak Acid & Alkali (Gas, Liquid)
Working Pressure		0.01 to 0.6MPa
Working Temperature		Max. +180℃
Seal Material		FKM, EPDM
Voltage	220VAC	15W			Start: 200W Keep: 5W		Start: 350W Keep: 10W
	24VDC	16W			28W		Start: 75W Keep: 25W

Main Dimension of PTFE Body Solenoid Valve:

1'' Anti Corrosive Solenoid Valve PTFE Body 24V DC 220V AC 0

Model	Dimension
Model	D	H	E	A	M	L	K	F
PTFE-15	70	127	56.5	18.5	M5	14	92	58
PTFE-20	80	136	70.5	20	M6	10	92	67
PTFE-25	95	145	78	25	M6	12	92	75
PTFE-32	120	200	110	31	M8	20	94	98
PTFE-40	130	220	113	33.5	M8	18	94	106
PTFE-50	150	249	140	43	M10	20	94	116
PTFE-65	180	262	152	49	M10	25	94	116
