0927100 3/8'' NC Brass Solenoid Valve For Screw Air Compressor

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	0927100

Payment & Shipping Terms:

Minimum Order Quantity:	10 pcs
Price:	$12 to $ 20 per pc
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	300000 sets per month

Contact Now

Detailed Product Description

Port Size:	3/8''	Orifice Size:	10mm
Function:	2 Way, NC	Action:	Pilot Operated
Seal Material:	NBR	Voltages:	24VDC, 110VAC, 220VAC
Working Pressure Range:	0.07 To 1.6 MPa	Application Examples:	Air Compressor
High Light:	0927100 Brass Solenoid Valve , 3/8'' Brass Solenoid Valve , 0927100 Pilot Acting Valve

0927100 3/8'' NC Brass Solenoid Valve For Screw Air Compressor

Solenoid Valves for Compressor soft start application:

Compressors must always have a soft start when switched on, to minimise surges and to protect the machine from damage. This relief start is often achieved by using a 2/2 solenoid valve. A few seconds after startup, a time lag relay switches in and energises the valve coil; the valve closes and the compressor is then enabled to compress the air into a pressurised storage vessel.

Main Dimension of 0927 & 0955 Series Air Compressor Solenoid Valve:

0927100 3/8'' NC Brass Solenoid Valve For Screw Air Compressor 0

Model	Orifice Size (mm)	Port Size (Inch)	a	b	c	e	h
0927000	8	1/4''	45	31.5	22	53	97
0955105							114
0927100	10	3/8''					97
0955205							114
0927200	12	1/2''					97
0955305							114
0927300	20	3/4''	65	44	30	86	113
0955405							130
0927400	25	1''					113
0955505							130
0927500	32	1 1/4''	95	47	31	131	136
0955605							153
0927600	40	1 1/2''					136
0955705							153
0927700	50	2''	112	55	39.5	163	155
0955805							172

Technical Data of 0927 & 0955 Series Air Compressor Solenoid Valve:

Model	0927000	0927100	0927200	0927300	0927400	0927500	0927600	0927700
Model	0955105	0955205	0955305	0955405	0955505	0955605	0955705	0955805
Orifice Size (mm)	8	10	12	20	25	32	40	50
Port Size (Inch)	1/4''	3/8''	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Effective Area (mm²)	20	40	60	110	190	300	400	500
Function	2 Way, Normally Closed: (0927 series), Normally Open: (0955 series)
Action	Diaphragm Pilot Operated
Working Pressure	0.07 to 1.6 MPa					0.1 to 1.6 Mpa
Working Temp	NBR: -5 to +80℃; FKM, EPDM: -5 to +150℃
Voltages	12VDC, 24VDC, 110VAC, 220VAC
