0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve

0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve

  • 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve
0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 0927700
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: $80 to $ 100 per pc
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Port Size: 2'' Orifice Size: 50mm
Function: 2 Way, Normally Closed Action: Diaphragm Pilot Operated
Seal Material: NBR Voltages: 24VDC, 110VAC, 220VAC
Working Pressure Range: 0.1 To 1.6 MPa Application Examples: Air Compressor
High Light:

0927700 Brass Solenoid Valve

,

2'' NC Brass Solenoid Valve

,

0927700 Screw Valve

0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve



As we all know, compressed air is an invaluable source of safe power in most industrial environments and production processes. The compressors that power this energy source often draw in air at ambient temperature with contaminants ranging from oil, water and a myriad of other particle types. This dirty air is often passed through an absorption vessel, filters and dryers to remove the contaminants and to dry and clean up the air. To control the flow of air in this situation the application requirement is for a solenoid valve with a high flow rate, a high-pressure withstand and one that is capable of a reliable operation in a high cycle environment.



For this type of application a brass body solenoid valve would often suffice but the valve is extremely dependable due to its low power consumption and special fabric diaphragm making it particularly suitable for high cycle rate applications.



Main Dimension of 0927 & 0955 Series Air Compressor Solenoid Valve:

0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 0

Model
Orifice Size
(mm)
Port Size
(Inch)
a
b
c
e
h
0927000
8
1/4''
45
31.5
22
53
97
0955105
114
0927100
10
3/8''
97
0955205
114
0927200
12
1/2''
97
0955305
114
0927300
20
3/4''
65
44
30
86
113
0955405
130
0927400
25
1''
113
0955505
130
0927500
32
1 1/4''
95
47
31
131
136
0955605
153
0927600
40
1 1/2''
136
0955705
153
0927700
50
2''
112
55
39.5
163
155
0955805
172



Technical Data of 0927 & 0955 Series Air Compressor Solenoid Valve:

Model
0927000
0927100
0927200
0927300
0927400
0927500
0927600
0927700
0955105
0955205
0955305
0955405
0955505
0955605
0955705
0955805
Orifice Size
(mm)
8
10
12
20
25
32
40
50
Port Size
(Inch)
1/4''
3/8''
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
Effective Area (mm²)
20
40
60
110
190
300
400
500
Function
2 Way, Normally Closed: (0927 series), Normally Open: (0955 series)
Action
Diaphragm Pilot Operated
Working Pressure
0.07 to 1.6 MPa
0.1 to 1.6 Mpa
Working Temp
NBR: -5 to +80℃; FKM, EPDM: -5 to +150℃
Voltages
12VDC, 24VDC, 110VAC, 220VAC



Brando Solenoid Valve Factory Production Video:



More Air Compressor Solenoid Valves for you to choose:



0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 1 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 2 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 3 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 4
COMBO OPTIMUM OPTIMUM-HP 3 Way Solenoid Valve
0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 5 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 6 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 7 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 8
6013 6014 6213 5404
0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 9 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 10 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 11 0927700 2'' NC Pilot Acting Air Compressor Brass Solenoid Valve 12
PU225A Series 0955 Series 0927 Series 2V025-08
