| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | RCA45T |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 50000pcs per month |
| Product Name: | Pulse Jet Valve | Pilot Size: | 1/8'', 1/4'' |
|---|---|---|---|
| Port Size: | 1 1/2'' | Series: | T |
| Structure: | Right Angle, Threaded Port | Body Material: | Aluminum |
| Diaphragm Material: | NBR | Working Temperature: | -5 To 80℃ |
| Working Pressure: | 5 To 125 Psi | Application: | Dust Collector |
| High Light: | Goyen Pulse Valve RCA45T,Goyen Pulse Valve 1 1/2'',Goyen Remote Pilot Pulse Valve |
||
1 1/2'' RCA45T Goyen Type Remote Pilot Pulse Jet Valve For Dust Collector
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the Pulse Controller. Pulse Jet Valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. Pulse jet valves are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Different pulse jet valve structure:
1. Threaded Type
2. Manifold Flat Mount Type
3. Dresser Nut Type
4. Straight Through Type
5. Flanged Type
Technical Data:
|
Model No
|
RCA15T
|
RCA20T
|
RCA25T
|
RCA35T
|
RCA45T
|
RCA50T
|
RCA62T
|
RCA76T
|
|
Orifice Size
|
15mm
|
20mm
|
25mm
|
35mm
|
45mm
|
50mm
|
62mm
|
76mm
|
|
Port Size
|
1/2''
|
3/4''
|
1''
|
1-1/2''
|
1-1/2''
|
2''
|
2-1/2''
|
3''
|
|
Remote Pilot Connection
|
1/8'', 1/4''
|
|||||||
|
Diaphragm Number
|
1
|
2
|
||||||
|
Working Pressure
|
5 to 125 psi
|
|||||||
|
Diaphragm Material
|
NBR (Standard), FKM (Optional)
|
|||||||
|
Body Material
|
Aluminum (diecast)
|
|||||||
|
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet)
|
|||||||
Ordering Code:
Main Dimension:
Our Production:
