| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BC-64 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 10000 pcs per month |
| Product Name: | Pulse Controller | Input Voltage: | 24VDC, 220VAC |
|---|---|---|---|
| Output Voltage: | 24VDC, 220VAC | Pulse Durtion: | 0.03 To 0.2 Seconds |
| Pulse Frequency: | 1 To 30 Seconds | Max Output Channel: | 64 Channel |
| High Light: | Dust Collector Timer Board,Pulse Jet Valve Sequence Controller,Sequential Pulse Timer Controller |
||
64 Line Dust Collector Timer Board Pulse Jet Valve Sequence Controller
Pulse valve controllers monitors and controls your pulse jet dust collector cleaning cycles. The right dust collector timer board option for you can vary depending on your plant’s unique requirements. The time for the pulse injection controller to output a continuous electrical signal is the pulse width. The time between two output signals is called the pulse interval. The time required for the controller to output electrical signal to complete a cycle is called pulse period.
Technical Data of Pulse Jet Valve Controller:
|
Model No
|
BC-08
|
BC-10
|
BC-12
|
BC-20
|
BC-24
|
BC-30
|
BC-36
|
BC-56
|
BC-64
|
|
Output Channel
|
1-8
|
1-10
|
1-12
|
1-20
|
1-24
|
1-30
|
1-36
|
1-56
|
1-64
|
|
Input Voltage
|
24VDC, 220VAC, Other voltage can be customized
|
||||||||
|
Output Voltage
|
24VDC, 220VAC, Other voltage can be customized
|
||||||||
|
Pulse Frequency
|
1 to 30 Seconds
|
||||||||
|
Pulse Durtion
|
0.03 to 0.2 Seconds
|
||||||||
|
Working Environment
|
1. -25°C~+55°C
2. The relative humidity of the air does not exceed 85%
3. No serious corrosion gas and conductive dust
4. No violent vibration or shock
|
||||||||
Main Dimension of Pulse Jet Valve Controller:
|
Output Lines
|
1-8
|
1-20
|
1-36
|
1-64
|
|
Dimension
|
115x135x65
|
160x160x95
|
230x150x90
|
248x188x105
|
Details Images of Pulse Jet Valve Controller:
Product Video of 64 Lines Pulse Controller:
