| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 4V420-15 |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 7 to 14 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Pneumatic Solenoid Valve | Working Fluid: | Air |
|---|---|---|---|
| Port Size: | In=Out=Exhaust=1/2'' | Valve Type: | Double Solenoid, 5 Way 2 Position |
| Operating Pressure: | 0.15 To 0.8 MPa | Proof Pressure: | 1.2MPa |
| Body Material: | Aluminum Alloy | Coil Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | AirTAC Pneumatic Solenoid Valve,1/2'' Pneumatic Solenoid Valve,4V420-15 Solenoid Valve |
||
AirTAC 1/2'' Pneumatic Solenoid Valve 4V420-15 Double Coil 24V DC
Pneumatic solenoid valves generally have a spool design. They consist of an aluminum body with a cylindrical hole. The different ports of the valve connect to the cylinder. A sliding spool in the cylinder has several seals along its length. By sliding the spool back and forth through the cylinder, different ports can be connected or closed off. Pneumatic solenoid valves are appointed with two numbers. The first number shows how many ports the valve has, and the second number is the amount of states. For example, a 2/2-way valve has two ports (in/out) and two states (open/closed). A 5/2-way valve has five ports and two states. Directional valves usually have two, three, or five ports.
Directional control valves are used in pneumatic systems to direct or stop the flow of compressed air or oil to their equipment. They are probably the most commonly used components in pneumatic systems, such as those used to drive cylinders, larger industrial valves or pneumatic tools. The valve can have two or more ports and can perform various circuit functions. The directional control valve can be operated in different ways, such as manual operation or solenoid operation.
Technical Data of 4V400 Series Solenoid Valve:
|
Model
|
4V410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air (to be filtered by 40μm filter element)
|
||||
|
Acting
|
internal pilot or external pilot
|
||||
|
Port Size
|
in=out=exhaust=1/2''
|
||||
|
Orifice Size
|
4V410-15, 4V420-15: 48.0mm² (Cv=2.82)
4V430C-15: 40.0mm² (Cv=2.35)
|
||||
|
Valve Type
|
5 way 2 position
|
5 way 3 position
|
|||
|
Operating Pressure
|
0.15 to 0.8 MPa (21 to 114 psi)
|
||||
|
Proof Pressure
|
1.2MPa (175psi)
|
||||
|
Temperature
|
-20 to 70℃
|
||||
|
Body Material
|
Aluminum Alloy
|
||||
|
Max Frequency
|
3 cycle/sec
|
||||
|
Voltages
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
||||
Main Dimension of 4V420-15 Solenoid Valve:
Video of 4V420-15 Solenoid Valve:
Production Video of Pneumatic Valve:
