Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel

Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel

  • Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel
Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball Power: Pneumatic
Pipe Connection: Female Thread Body Material: Stainless Steel (304, 316)
Seal Material: PTFE, TFM Working Medium: Neutral Gas, Air
Port Size: 1/2'' To 4''
High Light:

Pneumatic Two-Piece Ball Valve

,

1/2'' Pneumatic Ball Valve

,

Ball Valve Pneumatic Actuated

Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel



Pneumatic ball valve types:

Pneumatic brass ball valves have brass as their housing material. They are very common, durable, and can be used with water, compressed air, oils, non-aggressive media, and much more. They commonly have water or gas approvals.



Pneumatic PVC ball valves have PVC as their housing material. They are typically used for water management and irrigation applications as they are suitable for corrosive media (sea water), most acids and bases, salt solutions, organic solvents, and much more.



Pneumatic stainless steel ball valves have stainless steel as their housing material. They are typically used for aggressive and corrosive media. Stainless steel is also highly wear, temperature, and pressure resistant.



Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN



Main Dimension of Pneumatic Ball Valve:

Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 0

Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 1



More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 2 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 3 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 4 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 5
Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 6 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 7 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 8 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 9
Pneumatic Butterfly Valves
Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 10 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 11 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 12 Pneumatic Actuator Two-Piece Ball Valve 1/2'' DN15 Stainless Steel 13



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
