| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 7FA |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Connection: | Sub Base | Orifice Size: | 1.6mm, 2.5mm, 3mm, 4mm |
|---|---|---|---|
| Operation Mode: | 3 Way Normally Open | Operation: | Direct Acting |
| Body Material: | Brass | Working Medium: | Air, Water, Oil, Steam |
| Seal Material: | NBR, FKM, EPDM | Pressure Range: | 0 To 1.5 MPa |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||
| High Light: | 3 Way Solenoid Valve Coffee Machine,Solenoid Valve In Coffee Maker,Solenoid Valve For Coffee Machines |
||
3 Way Solenoid Valves For Espresso Coffee Machines 220V 230V 240V
Product Features of Brass Solenoid Valve:
1. Working Medium: Air, Water, Steam, Oil etc.
2. Working Pressure Range: 0 to 1.5 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Connection: Sub Base
5. Orifice Size: 1.6mm, 2.5mm, 3mm, 4mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Function: 3 Way Normally Open
9. Operation: Direct Acting
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of Brass Solenoid Valve:
3 Way Normally Open
Main Dimension of Sub Base Brass Solenoid Valve:
Brando Factory Production Video of Solenoid Valves:
More Coffee Machine Solenoid Valves for you to choose:
| Brass Solenoid Valve | |||
|
|
|
|
|
|
|
|
| Plastic Solenoid Valve | |||
|
|
|
|
|
|
|
|
| Manifold Solenoid Valve | ||
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
