1/8'' 4V120-06 5/2 Way Air Control Double Solenoid Pneumatic Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V120-06

Payment & Shipping Terms:

Minimum Order Quantity:	200pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	15 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=1/8''	Valve Type:	Double Solenoid 5 Port 2 Position
Voltage:	220VAC 110VAC 24VDC 12VDC	Connector:	Terminal & Grommet
Working Pressure:	0.15 To 0.8MPa(21-114psi)	Temperature:	-20 To +70℃
Max. Frequency:	5 Cycle/sec	Body Material:	Aluminum Alloy
Fluid:	Air (to Be Filtered By 40 μm Filter Element)	Application:	Automation
High Light:	1/8'' Pneumatic Valve , 4V120-06 Pneumatic Valve , AirTAC Type 4V120-06

1/8'' 4V120-06 5/2 Way Air Control Double Solenoid Pneumatic Valve

Two-position five-way solenoid valve
1. The piston rod must be flexible. Manual test, you should feel relaxed when pressing the piston rod. After releasing the hand, the piston
The rod can automatically return to the original position before being pressed under the action of the spring force. If it cannot be driven automatically, please remove the dust inside the valve body and the piston rod and treat it with high-quality lubricating oil to ensure the free movement of the piston rod.
2. Pilot valve The piston must be able to move easily and freely like the piston rod, and the treatment method is the same as above.
3. The air path for the pilot valve to work normally must be unobstructed.
The air path is unobstructed.
4. When the electromagnetic coil is energized under normal conditions, the closing part should be lifted and there will be a sound of pulling in. If abnormal check line
Whether the ring is burnt and whether there is debris inside the closing part, handle it by measuring and cleaning the debris.ete

Technical Data:

Model	4V110-06 4V120-06	4V130C-06 4V130E-06 4V130P-06	4V110-08 4V120-08	4V130C-08 4V130E-08 4V130P-08
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=1/8''		In=Out=1/4''
Orifice Size	5.5 mm2 (Cv=0.31)	5.0 mm2 (Cv=0.28)	12.00 mm2 (Cv=0.67)	9.00 mm2 (Cv=0.50)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Dimension Diagram:

1/8'' 4V120-06 5/2 Way Air Control Double Solenoid Pneumatic Valve 0

4V120(Grommet)

1/8'' 4V120-06 5/2 Way Air Control Double Solenoid Pneumatic Valve 1

4V120(Terminal)

Product Features:
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection
