Name: 140 bar High Pressure Brass Solenoid Valve For Water Air 1/8'' 1/4'' 3/8'' 24V 220V
Brand: BRANDO
SKU: 8CA
Rating: 4.9 (102 reviews)

Home Products Brass Solenoid Valve

140 bar High Pressure Brass Solenoid Valve For Water Air 1/8'' 1/4'' 3/8'' 24V 220V

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	8CA

Payment & Shipping Terms:

Minimum Order Quantity:	4pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	7 working days
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	5000pcs per month

Contact Now

Detailed Product Description

Product Name:	High Pressure Solenoid Valve	Port Size:	1/8'', 1/4'', 3/8''
Orifice Size:	1mm, 1.2mm, 1.5mm, 2mm, 2.5mm, 3mm	Body Material:	Brass
Seal Material:	PTFE	Working Media:	Water, Air, Gas, Liquid, Etc
Working Media Temperature:	-60 To +200℃	Max Pressure:	0 To 140 Bar
Operation:	Direct Acting	Function:	2 Way, Normally Closed
Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:	High Pressure Solenoid Valve 140 bar , High Pressure Brass Solenoid Valve , High Pressure Solenoid Valve 220V

140 bar High Pressure Brass Solenoid Valve For Water Air 1/8'' 1/4'' 3/8'' 24V 220V

Product Features:

1. Working Media: Water, Air, Gas, Liquid, etc
2. Working Pressure: 0 to 140 bar
3. Media Temperature: -60 to +200℃
4. Port Size: 1/8'', 1/4'', 3/8''
5. Orifice Size: 1mm, 1.2mm, 1.5mm, 2mm, 2.5mm, 3mm
6. Body Material: Brass
7. Seal Material: PTFE
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Technical Data:

Model No	Port Size	Orifice Size	Cv	Min Pressure	Max Pressure		Body	Seal	Voltage
Model No	Port Size	Orifice Size	Cv	Min Pressure	AC	DC	Body	Seal	Voltage
2 Way Normally Closed, Standard Coil
8CA1B010BXX	1/8'' 1/4'' 3/8''	1mm	0.09	0 bar	110 bar	120 bar	Brass	PTFE	12VDC 24VDC 24VAC 110VAC 220VAC
8CA1B012BXX		1.2mm	0.1	0 bar	100 bar	100 bar
8CA1B015BXX		1.5mm	0.13	0 bar	70 bar	95 bar
8CA1B020BXX		2mm	0.15	0 bar	50 bar	70 bar
8CA1B025BXX		2.5mm	0.18	0 bar	20 bar	45 bar
8CA1B030BXX		3mm	0.3	0 bar	10 bar	22 bar
2 Way Normally Closed, Energy Saving Coil
8CA2B010BXX	1/8'' 1/4'' 3/8''	1mm	0.09	0 bar	130 bar	140 bar	Brass	PTFE	12VDC 24VDC 24VAC 110VAC 220VAC
8CA2B012BXX		1.2mm	0.1	0 bar	120 bar	130 bar
8CA2B015BXX		1.5mm	0.13	0 bar	110 bar	120 bar
8CA2B020BXX		2mm	0.15	0 bar	90 bar	100 bar
8CA2B025BXX		2.5mm	0.18	0 bar	30 bar	70 bar
8CA2B030BXX		3mm	0.3	0 bar	22 bar	40 bar

Main Dimension:

Model No	Port	A	B	C	D	E	F
8CA1BXXXB01	1/8''	40.5	26	82	11	15	75
8CA2BXXXB01	1/8''	40.5	26	82	11	15	82
8CA1BXXXB02	1/4''	40.5	26	82	11	15	75
8CA2BXXXB02	1/4''	40.5	26	82	11	15	82
8CA1BXXXB03	3/8''	40.5	28	85	11	19	75
8CA2BXXXB03	3/8''	40.5	28	85	11	19	82

Our Production:

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
