| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 5404 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 50000 pcs per month |
| Port Size: | 1/4'', 3/8'', 1/2'' | Orifice Size: | 13mm |
|---|---|---|---|
| Function: | 2 Way, Normally Closed | Operation: | Servo-Assisted Piston |
| Body Material: | Brass | Seal Material: | PTFE + FKM |
| Pressure Range: | 1 To 50 Bar | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | Solenoid Valve 5404 A 12.0,High Pressure Solenoid Valve 50 bar,High Pressure Brass Solenoid Valve 1/2'' |
||
5404 A 12.0 50 bar High Pressure Brass Solenoid Valve 1/4'' 3/8'' 1/2'' 24V 230V
5404 is a servo-assisted piston valve available in Normally Closed and Normally Open versions. It has a piston to seal the valve, instead of a flexible rubber membrane. This robust design allows for high working pressures up to 40 bar. The port sizes range from 1/4" to 1". The dimensions of the orifice range from DN 13 to DN 25. A popular application for the 5404 valve is as a relief valve for compressors. A minimum differential pressure is required for the valve switching function. The solenoid coils are moulded with high-quality epoxy resin. In combination with a plug to DIN 43650 Form A, the valves satisfy degree of protection IP65.
Technical Data of 5404 Solenoid Valve:
| Model No |
Port Size (inch) |
Orifice Size (mm) |
Kv Value (m³/h) |
Pressure Range (bar) |
Body Material | Seal Material | Coil Voltage | Dimension | ||
| A | F | K | ||||||||
| 2 Way Normally Closed, Servo-Assisted Piston | ||||||||||
| 5404 | 1/4'' | 13 | 1.7 | 1 to 50 bar | Brass | PTFE+FKM |
12VDC 24VDC 24VAC 110VAC 220VAC |
72 | 32 | 97/106 |
| 3/8'' | 13 | 1.7 | 72 | 32 | 97/106 | |||||
| 1/2'' | 13 | 1.7 | 72 | 32 | 97/106 | |||||
| 3/4'' | 20 | 7 | 1 to 40 bar | 92 | 60 | 128 | ||||
| 3/4'' | 25 | 11 | 92 | 60 | 128 | |||||
| 1'' | 25 | 11 | 92 | 60 | 128 | |||||
| 2 Way Normally Open, Servo-Assisted Piston | ||||||||||
| 5404-NO | 1/4'' | 13 | 1.7 | 1 to 40 bar | Brass | PTFE+FKM |
12VDC 24VDC 24VAC 110VAC 220VAC |
72 | 32 | 103 |
| 3/8'' | 13 | 1.7 | 72 | 32 | 103 | |||||
| 1/2'' | 13 | 1.7 | 72 | 32 | 103 | |||||
