| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 5523 |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Production Name: | Solenoid Valve | Inlet Size: | R1/8'' |
|---|---|---|---|
| Outlet Size: | Hose Connection (6.2mm OD) | Orifice Size: | 2mm To 3mm |
| Body Material: | Brass | Seal Material: | EPDM, FKM |
| Working Medium: | Hot Water, Steam | Working Pressure Range: | 0 To 10 Bar |
| Function: | 2 Way Normally Closed | Coil Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Application: | Steam Iron, Steam Generator, Steam Station | Working Medium Temperature Range: | EPDM: -30 To +120 ℃, FKM: -30 To +150 ℃ |
| High Light: | CEME Solenoid Valve 5523,Steam Generator Solenoid Valve,Steam Station Solenoid Valve |
||
5523 CEME Type Solenoid Valve For Steam Iron Steam Generator Station 220V 230V
Product Feature:
1. Model No: 5523
2. Port Size: Inlet: R1/8'', Outlet: Hose Connection (6.2mm OD)
3. Orifice Size: 2mm to 3mm
4. Body Material: Brass
5. Seal Material: EPDM, FKM
6. Working Medium: Steam, Hot Water
7. Working Medium Temperature Range: EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
8. Working Pressure Range: 0 to 10 bar
9. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
10. Application: Steam Iron, Steam Boiler, Steam Generator, etc
Dimension and Data of 5523 Solenoid Valve:
|
Model No
|
5523
|
|
Port Size
|
Inlet: R1/8''
Outlet: Hose Connection (6.2mm OD)
|
|
Orifice Size
|
2mm to 3mm
|
|
Body Material
|
Brass
|
|
Seal Material
|
EPDM, FKM
|
|
Working Medium
|
Steam, Hot Water
|
|
Working Medium Temperature Range
|
EPDM: -30 ℃ to +120 ℃
FKM: -30 ℃ to +150 ℃ |
|
Working Pressure Range
|
0 to 10 bar
|
|
Operation
|
Direct Acting
|
|
Function
|
2 Way Normally Closed
|
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
BRANDO Solenoid Valve Production Video:
More Steam Iron Solenoid Valves for you to choose:
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
