| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3V310-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air (to Be Filtered By 40 μ M Filter Element) | Acting: | Internal Pilot Or External Pilot |
|---|---|---|---|
| Valve Type: | 3 Way 2 Position | Port Size: | 1/4'' |
| Pressure Range: | 0.15 To 0.8MPa | Max Pressure Resistance: | 1.5MPa |
| Body Material: | Aluminum Alloy | Voltage: | 12VDC, 24VDC, 110VAC, 220VAC |
| High Light: | Pneumatic Air Solenoid Valve,12VDC Pneumatic Solenoid Valve,Airtac 3V310-08 |
||
3V310-08 Airtac Type 3 Way Pneumatic Air Solenoid Valve 1/4'' 12VDC
BRANDO is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).
Pneumatic valves are electrically controlled to direct air flow to sequence operations in pneumatic systems. Pneumatic valves are used to control cylinders, rotary actuators, grippers and other pneumatic devices. Use a manifold to simplify plumbing for a bank of valves. Modular systems even allow networked control of valve groups.
Technical Data of 3V300 Series Pneumatic Solenoid Valves:
| Model No |
3V310-08 |
3V320-08 |
3V310-10 |
3V320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||
| Port Size | In=Out=1/4'' | In=Out=3/8'' | ||
| Orifice Size |
25.0mm² (Cv=1.39) |
30.0mm² (Cv=1.67) |
||
| Valve Type | 3 Way 2 Position | |||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||
| Proof Pressure | 1.5MPa (215PSI) | |||
| Temperature (℃) | -20 to +70 | |||
| Body Material | Aluminum Alloy | |||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||
| Coil Protection Class | IP65 | |||
| Activating Time | 0.05 second and below | |||
Dimension of 3V310-08 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valves:
