| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | DCY |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/4'', 3/8'' | Orifice Size: | Body: 1.6mm, Top: 2.3mm |
|---|---|---|---|
| Operation Mode: | 3 Way, Normally Closed | Action: | Direct Acting |
| Body Material: | Brass | Seal Material: | NBR, EPDM, FKM, Silicone |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Pressure Range: | 0 To 9 Bar |
| High Light: | 3-Way Solenoid Valve,KSD Solenoid Valve,KSD DCY |
||
DC231Y DC221Y DC241Y KSD Type 3-Way Brass Solenoid Valve 24V 110V 220V
3 Way brass direct acting solenoid valve, suitable for neutral gases and liquid, including compressed air, natural gases, water, hydraulic oil and technical vacuum. Compact design, high quality VITON seal. 1/4'', 3/8'' port sizes, 24VDC, 110VAC, 220VAC voltages, other voltages are optional.
Main Dimension of Solenoid Valve:
Technical Data of Solenoid Valve:
DC-Y Series
3 Port 2 Position Solenoid Valve
|
Pipe Size
|
Orifice Size
|
Cv Value
|
Working Pressure Range (bar)
|
Code
|
||
|
Min
|
Max-AC
|
Max-DC
|
||||
|
1/4'', 3/8''
|
Top:
2.3mm
Body: 1.6mm
|
0.21
|
0
|
7
|
7
|
DC231Y (AC220V)
DC221Y (AC110V)
DC241Y (DC24V)
|
FB Series
2 Port 2 Position Solenoid Valve
|
Pipe Size
|
Orifice Size
(mm/inch)
|
Cv Value
|
Working Pressure Range (bar)
|
Code
|
||
|
Min
|
Max-AC
|
Max-DC
|
||||
|
1/4''
|
2.4 (3/32)
|
0.21
|
0
|
20
|
10
|
FB2C
|
|
3.2 (1/8)
|
0.33
|
12
|
7
|
FB2D
|
||
|
4 (5/32)
|
0.43
|
9
|
5
|
FB2E
|
||
|
3/8''
|
5 (3/16)
|
0.50
|
6
|
3
|
FB3F
|
|
Brando Factory Production of Solenoid Valves:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
