Name: 2'' 2L-50 US-50 Uni-D Type Solenoid Valve For Steam 24VDC 220VAC
Brand: Brando
SKU: US-50
Rating: 4.7 (177 reviews)

Home Products Brass Solenoid Valve

2'' 2L-50 US-50 Uni-D Type Solenoid Valve For Steam 24VDC 220VAC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	US-50

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	2''	Orifice Size:	50mm
Operation Mode:	2 Way, Normally Closed	Action:	Piston Piloted Operated
Working Fluids:	Hot Water, Steam	Body Material:	Brass, Stainless Steel
Seal Material:	PTFE	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0.1 To 1.5 MPa	Temperature Range:	-20 To +185 ℃
High Light:	2L-50 Solenoid Valve , Steam Solenoid Valve 2'' , Uni-D US-50

2'' 2L-50 US-50 Uni-D Type Solenoid Valve For Steam 24VDC 220VAC

US Series Steam Solenoid Valve Function:

Steam solenoid actuated valves are typically 2/2 way, being 2 ports inlet and outlet and 2 positions either OPEN or CLOSED. This function can be either normally closed (most commonly used) or normally open.

2 way normally closed - meaning fail-safe closed requires electrical power to open.

2 way normally open - meaning fail-safe open requires electrical power to close.

US Series Steam Solenoid Valve Operation:

Pilot Assisted - the valve operates indirectly from the coil via an internal pilot, these operate with a pressure differential i.e. a minimum pressure difference between inlet and outlet pressure typically either 0.5 Bar.

Sometimes referred to as pilot operated, servo assisted and floating piston valves.

Main Dimension of Steam Solenoid Valve:

2'' 2L-50 US-50 Uni-D Type Solenoid Valve For Steam 24VDC 220VAC 0

US Series	2L Series	A	B	C	Port Size
US-10	2L-10	82	42	146	3/8''
US-15	2L-15				1/2''
US-20	2L-20				3/4''
US-25	2L-25	90	54	162	1''
US-35	2L-35	110	75	185	1 1/4''
US-40	2L-40	110	75	185	1 1/2''
US-50	2L-50	120	77	195	2''

Technical Data of Steam Solenoid Valve:

2L Series	2L-10	2L-15	2L-20	2L-25	2L-35	2L-40	2L-50
US Series	US-10	US-15	US-20	US-25	US-35	US-40	US-50
Orifice Size	17	17	17	22	30	30	50
Port Size	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Hot Water, Steam
Action	Direct Acting, Servo Pilot Operated
Function	2 Way, Normally Closed
Body Material	Brass, Stainless Steel
Seal Material	PTFE, FKM
Pressure Range	0.1 to 1.5MPa
Temp. Range	PTFE: -20 to +185℃, FKM: -10 to +150℃
Coil Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
