| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | PSU |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Silencer Muffler | Tube OD (Inch): | 1/8", 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
|---|---|---|---|
| Material: | Plastic | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | -10 To +250℃ | Working Medium: | Compressed Air |
| High Light: | Plastic Pneumatic Silencer,Plastic Pneumatic Muffler,Pneumatic Mufflers |
||
Plastic Pneumatic Solenoid Valve Silencer Muffler 1/8'' 1/4'' 3/8'' 1/2''
Pneumatic air silencers, also commonly called pneumatic mufflers, are a cost-effective and simple solution to reduce noise level and unwanted discharge of contaminants from pneumatics. Silencers can also include adjustable throttle valves to control the flow rate of air as it exits the silencer. Flow rate control with a silencer throttle valve can be useful to control the speed of a driving device and works similar to a needle valve. For example, pneumatic cylinders are commonly equipped with a throttle valve to control the piston actuation and/or retraction speed.
Technical data of Pneumatic Silencer Muffler:
|
Model
|
Working Medium
|
Working Pressure
(MPa)
|
Working Temp
(℃)
|
Circulation Capacity
|
Noise Effect
|
|
|
"S" data
|
Nominal Flux
|
|||||
|
-2.5
|
Compressed Air
|
0 to 0.8
|
-10 to +250
|
5
|
200L/Min
|
≥20dB
|
|
-6
|
20
|
960L/Min
|
||||
|
-8
|
40
|
1920L/Min
|
||||
|
-10
|
60
|
2880L/Min
|
||||
|
-15
|
110
|
5280L/Min
|
||||
|
-20
|
190
|
9120L/Min
|
||||
|
-25
|
300
|
10000L/Min
|
||||
|
-32
|
400
|
19200L/Min
|
≥25dB
|
|||
|
-40
|
650
|
31200L/Min
|
||||
|
-55
|
700
|
33600L/Min
|
||||
Dimension of Pneumatic Silencer Muffler:
|
Model No
|
M
|
φD
|
L1
|
L
|
S1
|
S
|
|
PSU-6
|
1/8''
|
16
|
7
|
41
|
8
|
14
|
|
PSU-8
|
1/4''
|
21
|
10
|
64
|
12
|
18
|
|
PSU-10
|
3/8''
|
25
|
13
|
85
|
15
|
22
|
|
PSU-15
|
1/2''
|
30
|
14
|
94
|
19
|
26
|
|
PSU-20
|
3/4'
|
37
|
16
|
106
|
24
|
32
|
|
PSU-25
|
1''
|
46
|
18
|
144
|
30
|
36
|
