| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4L310-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Manual Control Direct Acting Type |
|---|---|---|---|
| Port Size: | 3/8'' | Valve Type: | 5 Way 2 Position |
| Pressure Range: | 0 To 1.0MPa (0 To 145 Psi) | Max Pressure Resistance: | 1.5 MPa (215 Psi) |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| High Light: | Push Pull Valve 5/2 Way,5/2 Manual Pneumatic Valve,Airtac 4L310-10 |
||
4L310-10 Airtac Type Pneumatic Manual Push Pull Valve 5/2 Way
Feature of Push Pull Pneumatic Valve:
1. The valve body is made of high-quality sealed PVC material and aluminum alloy structure, making the whole valve body connection more tight and firm;
2. The round control handle is in the same direction as the shaft, easy to operate, reliable and precise positioning;
3. High-accuracy valve rod and sealing design ensure good breathability;
4. The inner hole is processed by a special process, with low resistance and long service life;
5. Small size, light weight, good sealing and easy installation.
Technical Data of 4L series Push Pull Valve:
| Model | 4L110-06 | 4L210-06 | 4L210-08 | 4L310-08 | 4L310-10 |
| Fluid | Air (to be filtered by 40μm filter element) | ||||
| Operating | Manual control direct acting type | ||||
| Port Size | 1/8'' | 1/4'' | 3/8'' | ||
| Orifice Size (Cv) |
10.2mm² (Cv=0.6) |
4L210-08: 17.0mm² (Cv=1.0) |
4L310-10: 28.0mm² (Cv=1.65) |
||
| Valve Type | 5/2 Way | ||||
| Pressure Range | 0 to 1.0MPa (0 to 145 psi) | ||||
| Proof Pressure | 1.5 MPa (215 psi) | ||||
| Temperature | -20 to +70℃ | ||||
| Body Material | Aluminum Alloy | ||||
Ordering Code of 4L series Push Pull Valve:
Dimension of 4L310-10 Push Pull Valve:
Inner Structure of 4L series Push Pull Valve:
Production Video of BRANDO Pneumatic Valves:
