| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | DMF-Y-50S |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Membrane | Membrane Material: | NBR, VITON |
|---|---|---|---|
| 1 Set: | 1pc DB112 Diaphragm, 1pc Spring | Fitted Pulse Valve Model: | VNP212, VEM212, VNP312, VEM312, VNP412, VEM412 |
| High Light: | Mecair Diaphragm DB112,Mecair Membrane DB112,Mecair Pulse Valve Membrane |
||
DB112 DB112/G Diaphragm For Mecair Pulse Valve VNP212 VNP312 VNP412
DB112 ( DB112/G ) Diaphragm ( Membrane ) for Mecair pulse valve VNP212, VEM212, VNP312, VEM312, VNP412, VEM412; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.
Ordering Code of Diaphragm For Mecair Pulse Valve:
|
Ordering code
|
Fitted valve code
|
Valve port size
|
Material
|
|
DB16/G
|
VNP206, VEM206, VNP306, VEM306
|
3/4''
|
NBR
|
|
DB18/G
|
VNP208, VEM208, VNP308, VEM308,
VNP408, VEM408
|
1''
|
NBR
|
|
DB18M
|
VNP608, VEM608, VNP708, VEM708
|
1'', 1-1/2''
|
NBR
|
|
DB112/G
|
VNP212, VEM212, VNP312, VEM312,
VNP412, VEM412
|
1-1/2''
|
NBR
|
|
DB114/C
|
VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714 |
1-1/2''
|
NBR
|
|
DB116/C
|
VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716 |
2''
|
NBR
|
|
DB120/C
|
VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720 |
2-1/2'', 3''
|
NBR
|
|
Tips: EPDM, FKM all available.
|
|||
Dimension of DB112 Diaphragm:
Video of DB112 Diaphragm:
Pictures of Pulse Valve Membrane Production:
