| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | AFC, BFC |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | bubble bag, inner box, carton, then pallet |
| Delivery Time: | 7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Product Name: | Filter Regulator Lubricator | Model: | AFC1500, AFC2000, BFC2000, BFC3000, BFC4000 |
|---|---|---|---|
| Fluid: | Air | Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' |
| Filtering Grade: | 40 μm Or 5 μm | Max Pressure: | 1.0Mpa (145Psi) |
| Proof Pressure: | 1.5Mpa (215Psi) | Capacity Of Drain Bowl: | 15CC, 60CC |
| Capacity Of Oil Bowl: | 25CC, 90CC | Recommended Lubricant: | ISO VG 32 Or Equivalent |
| High Light: | Filter Regulator Lubricator 1/8'',Air Filter Regulator Lubricator Combination,Airtac AFC1500 |
||
AFC1500 Airtac Type 1/8'' Air Filter Regulator Lubricator Combination
Filter regulator lubricator assembles configurations including air filter, regulator, lubricator, and gauge. The Filter Regulator Lubricator (F.R.L.) is designed to remove compressor lubricants, dirt and water from the air stream. The built in regulator can reduce the air pressure to extend the life of your tools. The lubricator adds atomized tool oil to the air stream to lubricate your pneumatic tools. If you need regulated, clean air for your tools, the F.R.L. is an effective component of your air system. BRANDO provide different combination units and filter regulator lubricator for you to select.
Specification of AFC, BFC series Filter Regulator Lubricator:
| Model | AFC1500 | AFC2000 | BFC2000 | BFC3000 | BFC4000 | |
| Fluid | Air | |||||
| Port Size | 1/8'' | 1/4'' | 1/4'' | 3/8'' | 1/2'' | |
| Filtering Grade | 40μm or 5μm | |||||
| Pressure Range |
Semi-auto and automatic drain: 0.15 to 0.9 MPa (20 to 130 psi) Manual drain: 0.5 to 0.9 MPa (7 to 130 psi) |
|||||
| Max Pressure | 1.0 MPa (145 psi) | |||||
| Proof Pressure | 1.5 MPa (215 psi) | |||||
| Temperature Range | -5 to 70℃ (unfreeze) | |||||
| Capacity of drain bowl | 15CC | 60CC | ||||
| Capacity of oil bowl | 25CC | 90CC | ||||
| Recommand lubricant | ISO VG 32 or equivalent | |||||
| Constitute | Filter-Regulator | AFR1500 | AFR2000 | BFR2000 | BFR3000 | BFR4000 |
| Lubricator | AL1500 | AL2000 | BL2000 | BL3000 | BL4000 | |
Ordering Code of AFC, BFC series Filter Regulator Lubricator:
Inner Structure of AFC, BFC series Filter Regulator Lubricator:
Dimension of AFC, BFC series Filter Regulator Lubricator:
Other pneumatic products BRANDO supply:
| 2/2 Way Pneumatic Valves | 3/2 Way Pneumatic Valves | 5/2 Way Pneumatic Valves | 5/3 Way Pneumatic Valves |
|
|
|
|
| Namur Solenoid Valves | Air Pilot Valves | Pneumatic Cylinders | Silencers and Fittings |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
