Name: 4V230C-08 5/3 Way 1/4'' Double Solenoid Closed Center Pneumatic Valve
Brand: Brando
SKU: 4V230C-08
Rating: 4.5 (116 reviews)

Home Products Pneumatic Solenoid Valve

4V230C-08 5/3 Way 1/4'' Double Solenoid Closed Center Pneumatic Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V230C-08

Payment & Shipping Terms:

Minimum Order Quantity:	200 PCS
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	In=Out=1/4'' Exhaust=1/8''	Valve Type:	Double Solenoid 5 Port 3 Position
Voltage:	220VAC 110VAC 24VDC 12VDC	Connector:	Terminal & Grommet
Working Pressure:	0.15 To 0.8MPa(21-114psi)	Temperature:	-20 To +70℃
Max. Frequency:	5 Cycle/sec	Body Material:	Aluminum Alloy
Fluid:	Air (to Be Filtered By 40 μm Filter Element)	Application:	Automation
High Light:	4V230C-08 Pneumatic Valve , 5/3 Way Pneumatic Valve , AirTAC Type 4V230C-08

4V230C-08 5/3 Way 1/4'' Double Solenoid Closed Center Pneumatic Valve

5/3 Way Pneumatic Solenoid Valve:
Solenoid valves are an efficient method of converting electrical signals into pneumatic functions. Applying electricity to the solenoid quickly directs air through the valve and into the circuit.

Valves can be designated as internally piloted or externally piloted. Externally piloted valves use an external source of air pressure. Internally piloted use an internal source of air pressure.

Solenoid valves are controlled by the action of the solenoid and typically control the flow of water or air as a switch. If the solenoid is active (current is applied), it opens the valve. If the solenoid is inactive (current does not exist), the valve stays closed.

Technical Data:

Model	4V210-06 4V220-06	4V230C-06 4V230E-06 4V230P-06	4V210-08 4V220-08	4V230C-08 4V230E-08 4V230P-08
Fluid	Air(to be filtered by 40 μ m filter element)
Acting	Internal pilot or external pilot
Port Size	In=Out=Exhaust=1/8''		In=Out=1/4'' Exhaust=1/8''
Orifice Size	25.00 mm2 (Cv=0.78)	18.00 mm2 (Cv=0.67)	30.00 mm2 (Cv=0.89)	18.00 mm2 (Cv=0.67)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Dimension Diagram:

4V230C-08 5/3 Way 1/4'' Double Solenoid Closed Center Pneumatic Valve 0

4V230(Grommet)

4V230C-08 5/3 Way 1/4'' Double Solenoid Closed Center Pneumatic Valve 1

4V230(Terminal)

Product Features:
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection
