4V210-08 Airtac Type Single Solenoid Pneumatic Air Control Valve

4V210-08 Airtac Type Single Solenoid Pneumatic Air Control Valve

Pneumatic solenoid valve takes an electrical signal (ac or dc Voltage) and opens or closes the air supply going to your pneumatic actuator. Very basic solenoids consist of an electromagnetic coil, a plunger or piston, a piston return spring, and a valve body. When you apply electrical power to the coil, it attracts the piston and causes it to move inside the valve body. This, in turn, opens or closes ports inside the valve body allowing your air supply to operate the pneumatic actuator. When the electric supply is removed, the piston spring returns the piston to its original position and shuts off the air supply to the pneumatic actuator.

To Connect a DIN Coil:

Remove the screw from the plastic housting & unplug from the DIN coil.
Use the removed screw to push the terminal block out of the plastic DIN housing.
Note the "1", "2", and ground "⏚" symbols.
For DC DIN Coils, connect "1" to your positive lead and "2" to your negative lead.
For AC DIN Coils, connect "1" to your HOT lead, "2" to your NEUTRAL lead, and "⏚" to your ground lead, if required.

Data of 4V200 Series Pneumatic Solenoid Valves:

Dimension of 4V210-08 Pneumatic Solenoid Valve:

Video of 4V210-08 Pneumatic Solenoid Valve:

Production Video of Pneumatic Solenoid Valve:

More Pneumatic Products for you to choose:

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
