| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | MP-C-011 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 set per month |
| Product Name: | MP-C-011 Solenoid Coil | Voltage: | 24VAC, 110VAC, 120VAC, 220VAC, 240VAC (50/60Hz) |
|---|---|---|---|
| Reference No: | 099257-009-D, 099257-016-D, 099257-005-D, 099257-008-D, 099257-001-D 099257-004G, 099257-014G, 099257-006G | Connection Type: | Flying Leads |
| Insulation Class: | F, H | Temperatrue Class: | T, B |
| Repair Solenoid Valve Model: | 29515, 29547, 29698, 18724, 18721, 17120, 17121 | Application: | Henny Penny Fryer |
| High Light: | Solenoid Coil 24V AC,Solenoid Coil MP-C-011,Henny Penny Solenoid Coil |
||
Solenoid Coil MP-C-011 24V AC For Henny Penny Fryer 29547 Valve
Working principle of solenoid valve coil:
The purpose of a solenoid valve coil is to convert electrical energy into linear motion. The coil consists of copper wire wound around a hollow form. When electric current flows through the coil, a magnetic field is created. This is accomplished by placing a ferromagnetic core inside the coil. In a solenoid valve, the ferromagnetic core is called the valve plunger. When the current flows through the coil, the lines of magnetic flux turn the plunger into an electromagnet. The magnetic field causes the plunger to slide further up into the coil, opening the valve body orifice or pilot orifice.
Dimension & Data of MP-C-011 Solenoid Coil:
|
Model
|
MP-C-011
|
|
Connection Type
|
Flying Leads
|
|
Voltage
|
24VAC, 110VAC, 120VAC, 220VAC, 240VAC (50/60Hz)
|
|
Insulation Class
|
H, F
|
|
Temperature Class
|
T, B
|
|
Model
|
BAPC216049003
|
|
Function
|
2/2 Way, Normally Closed
|
|
Tube Material
|
Stainless Steel
|
|
Shading Ring Material
|
Copper
|
|
Seat Type
|
Thread
|
|
Fitted Coil
|
MP-C-011
|
|
Application Example
|
Henny Penny Fryer
|
Multi-angle display of MP-C-011 solenoid coil:
MP-C-011 Coil surface parameter printing display:
Brando Factory Production Video of Solenoid Coils:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
