4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt

4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt

4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt
video
4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V310-08
Payment & Shipping Terms:
Minimum Order Quantity: 200 PCS
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Type: 5/2 Way, Single Solenoid Port Size: In=Out=Exhaust=1/4''
Pressure Range: 0.15 To 0.8MPa (21 To 114PSI) Max Pressure Resistance: 1.5MPa (215PSI)
Body Material: Aluminum Alloy Max. Frequency: 5 Cycle / Second
High Light:

Air Solenoid Valve 5/2 Way

,

Pneumatic Solenoid Valve 24 Volt

,

4V310-08-DC24V Airtac

4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt



Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.



This 4V310-08 solenoid valve is the 1/4'' 5 way 2 Position Pneumatic Solenoid Valve. Itis a switch for routing air to any pneumatic device, usually an actuator, allowing a relatively small signal to control a large device. It is also the interface between electronic controllers and pneumatic systems. This valve allows pneumatic control of position, flow, pressure and temperature.



Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec


Dimension of 4V310-08 Pneumatic Solenoid Valve:

4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt 0



Product video of 4V310-08 Pneumatic Solenoid Valve:


Production Video of Pneumatic Solenoid Valve:



More Pneumatic Products for you to choose:

4V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt 14V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt 24V310-08-DC24V Airtac Type Pneumatic Air Solenoid Valve 5/2 Way 24 Volt 3pneumatic fast fittings

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings
