3V110-06 Airtac Type Pneumatic Solenoid Valve 3V110-06-NC 3V110-06-NO

3V110-06 Airtac Type Pneumatic Solenoid Valve 3V110-06-NC 3V110-06-NO

Circuit function of 3 way pneumatic solenoid valves:

The 3/2 way pneumatic solenoid valve has three connection ports and two states. The three ports are:

1. inlet (P, 1),
2. outlet (A, 2)
3. exhaust (R, 3)

The two states of the valve are open and closed. When the valve is open, air flows from the inlet (P, 1) to the outlet (A, 2). When the valve is closed, air flows from the outlet (A, 2) to the exhaust (R, 3). A valve that is closed in non-actuated state is normally closed (N.C.), the opposite is called normally open (N.O.).

Technical Data of 3V100 Series Pneumatic Solenoid Valves:

Dimension of 3V110-06 Pneumatic Solenoid Valve:



Production Video of Pneumatic Solenoid Valves:
