| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3V1-06 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $3 to $ 5 per pc |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air (to Be Filtered By 40 μ M Filter Element) | Action: | Direct Acting |
|---|---|---|---|
| Function: | 3 Way, Normally Closed (NC) | Orifice Size: | 1.0mm |
| Port Size: | 1/8'' | Pressure Range: | 0 To 0.8MPa |
| Max Pressure Resistance: | 1.2MPa | Body Material: | Aluminum Alloy |
| Max. Frequency: | 10 Cycle / Second | Voltage: | 12VDC, 24VDC, 110VAC, 220VAC |
| High Light: | 3V1-06 Pneumatic Solenoid Valve,3/2 Way Pneumatic Solenoid Valve,3 Way Solenoid Valve Pneumatic |
||
3V1-06 Airtac Type Pneumatic Solenoid Valve 3/2 Way DC24V
Description
1. Product: pneumatic solenoid valve
2. Model: 3V1-06
3. Port size/diameter: 1/8 inch
4. Pressure: 0~0.8 MPa
5. Ambient temperature: -50~+50 degree
6. Type: 2 position, 3 way
7. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Specification:
1. Structure in sliding column mode: good tightness and sensitive reaction.
2. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life.
3. No need to add oil for lubrication.
4. It is available to form integrated valve group with the base to save installation space.
5. Affiliated manual devices are equipped to facilitate installation and debugging.
6. Several voltage grades are optional.
Technical Data of 3V1 Series Pneumatic Solenoid Valves:
| Model | 3V1-M5 | 3V1-06 | 3V1-08 |
| Medium | Air (to be filtered by 40 μ m filter element) | ||
| Action | Direct Acting | ||
| Way & Position | 3 Port 2 Position | ||
| Port Size | M5 | 1/8'' | 1/4'' |
| Orifice Size | 1.0mm | ||
| Pressure Range | 0 to 0.8MPa | ||
| Max. Resistance Pressure | 1.2 MPa | ||
| Coil Voltage | 12VDC, 24VDC, 110VAC, 220VAC | ||
| Coil Power | AC: 5.5VA, DC: 4.8W | ||
| Max. Frequency | 10 cycle/sec | ||
Dimension of 3V1-06 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valves:
More Pneumatic Products for you to choose:
2/2 Way 3/2 Way 5/2 Way, Single Solenoid
5/2 Way, Double Solenoid 5/3 Way, Double Solenoid Pneumatic Hose Fittings
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
