| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 2V025-08 |
| Minimum Order Quantity: | 300pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 7 to 14 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air, Water, Oil | Action: | Direct Acting |
|---|---|---|---|
| Function: | 2 Way, Normally Closed (NC) | Orifice Size: | 2.5mm |
| Port Size: | 1/4'' | Pressure Range: | 0 To 1.0MPa (0 To 145PSI) |
| Max Pressure Resistance: | 1.5MPa (215PSI) | Body Material: | Aluminum Alloy |
| Seal Material: | NBR (Standard), VITON (Option) | Min. Action Time: | 0.05 Second And Below |
| High Light: | 2/2 Way Pneumatic Solenoid Valve,2V025-1/4 Solenoid Valve,Pneumatic Solenoid Valve 24VDC |
||
2V025-1/4 2/2 Way Pneumatic Solenoid Valve 24VDC 12VDC
1. Model: 2V025-08 Solenoid Valve
2. Function: 2 Way Normally Closed
3. Port Size: 1/4'' (Please air in the direction of the arrow above the product)
4. Temperature Range: -10 to 80 ℃
5. Pressure Range: 0~1.0MPa (0~145PSI)
6. Feature: This solenoid valve is a Zero differential solenoid valve which can be operated at 0 PSI (Vacuum). A valve response rate of up to 5 times per secon
Technical Data of 2V Series Pneumatic Solenoid Valves:
Dimension of 2V025-08 Pneumatic Solenoid Valve:
Product Video of 2V025-08 Pneumatic Solenoid Valve:
