| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCKH-3Y-Z |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fittings | Type: | Male Run Tee |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | 0 To +60℃ | Connection: | Push In |
| High Light: | Pneumatic Air Hose Fittings,Pneumatic Air Coupling,Pneumatic Air Coupler |
||
Pneumatic Air Hose Fittings Male Run Tee 1/8'' 1/4'' 3/8'' 1/2''
Brass push to connect fittings are available in few common types, straight, elbow, tee, reducer, union, bulkhead, plug, etc. Nickel plated brass push to connect fittings are recommended for compressed air, pneumatic, instrumentation, circuit, lubricant and cooling lines. Brass push to connect fittings are solution for pneumatic applications and other fluids in aggressive environment.
Accommodate metric tubing O.D ranging from 4 mm to 16 mm and inch tubing O.D 1/8" to 1/2". Thread sizes range is from BSPP, BSP, G 1/8" to BSPP, BSP, G 1/2".
Technical data of Pneumatic Hose Fittings:
Specifications of Male Run Tee Brass Pneumatic Hose Fittings:
|
Model No
|
D
|
M
|
L1
|
L2
|
L
|
L'
|
S
|
|
BCKH-3Y-Z2.5
|
4
|
M5X0.8
|
6
|
4
|
23
|
18
|
10
|
|
BCKH-3Y-Z4
|
6
|
M8X1
|
7
|
4
|
25
|
19
|
12
|
|
M10X1
|
7
|
4
|
19
|
13
|
|||
|
G1/8''
|
6
|
4
|
20
|
12
|
|||
|
G1/4''
|
8
|
5
|
22
|
14
|
|||
|
G3/8''
|
6
|
4
|
14
|
17
|
|||
|
G1/2''
|
8
|
5
|
25
|
22
|
|||
|
BCKH-3Y-Z6
|
8
|
M10X1
|
7
|
4
|
27
|
20
|
13
|
|
G1/8''
|
6
|
5
|
20
|
12
|
|||
|
G1/4''
|
8
|
5
|
22
|
14
|
|||
|
G3/8''
|
9
|
5
|
24
|
17
|
|||
|
G1/2''
|
10
|
5
|
25
|
22
|
|||
|
BCKH-3Y-Z8
|
10
|
M12X1.25
|
9
|
5
|
30
|
24
|
15
|
|
G1/8''
|
6
|
5
|
21
|
14
|
|||
|
G1/4''
|
8
|
5
|
24
|
14
|
|||
|
G3/8''
|
9
|
5
|
25
|
17
|
|||
|
G1/2''
|
10
|
6
|
26
|
22
|
|||
|
BCKH-3Y-Z10
|
12
|
M16X1.5
|
10
|
5
|
32
|
26
|
19
|
|
G1/8''
|
6
|
5
|
23
|
16
|
|||
|
G1/4''
|
8
|
5
|
25
|
16
|
|||
|
G3/8''
|
9
|
5
|
26
|
17
|
|||
|
G1/2''
|
10
|
6
|
28
|
22
|
Product Video of BRANDO Brass Pneumatic Hose Fittings:
List of All Push To Connect Brass Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
