Name: 1090/6 3/4 Inch SAE Flare Brass Refrigeration Solenoid Valve
Brand: Brando
SKU: 1090/6
Rating: 4.8 (124 reviews)

Home Products Refrigeration Solenoid Valve

1090/6 3/4 Inch SAE Flare Brass Refrigeration Solenoid Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	1090/6

Payment & Shipping Terms:

Minimum Order Quantity:	50 PCS
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Screw Connections:	3/4"SAE	Power:	Solenoid
Media:	Refrigerant	Structure:	Diaphragm Pilot Operated
Material:	Brass	Function:	Normally Closed
Voltages:	AC110V, AC220V, DC24V	Ambient Temperature:	-35 - 105 °C
Application:	Refrigeration Parts	Refrigerants:	R125 R134a R152a R22 R404A R407A R407C
High Light:	1090/6 Refrigeration Solenoid Valve , Brass Refrigeration Solenoid Valve , Castel Refrigerator Solenoid Valve

1090/6 3/4 Inch SAE Flare Brass Refrigeration Solenoid Valve

Technical Data:

Operating Principles	Model Number	SAE Port	Seat size nominal Ø [mm]	Kv Factor [m3/h]	PS [bar]	TS[℃]		TA[℃]
						min	max	min	max
Direct Acting	1020/2	1/4''	2, 5	0, 175	45	-35	+110	-35	+50
	1020/3	3/8''	3	0, 23
Diaphragm Pilot Operated	1064/3	3/8''	6, 5	0, 80	45	-35	+105	-35	+50
	1064/4	1/2''
	1070/4	1/2''	12, 5	2, 20
	1070/5	5/8''		2, 61
	1090/5	5/8''	16, 5	3, 80
	1090/6	3/4''		4, 80
Piston Pilot Operated	1034/3	3/8''	6, 5	1, 00	45	-35	+110	-35	+50
	1034/4	1/2''
	1040/4	1/2''	12, 5	2, 40
	1040/5	5/8''		3, 00
	1050/5	5/8''	16, 5	3, 80
	1050/6	3/4''		4, 80

Dimension:

1090/6 3/4 Inch SAE Flare Brass Refrigeration Solenoid Valve 0

Replacement Castel Type Solenoid Coil:

1090/6 3/4 Inch SAE Flare Brass Refrigeration Solenoid Valve 1

Fruit storage cabinet Working Principle
The fresh-keeping cabinet rolling piston compressor is generally a vertical structure. The compressor is installed in the lower part of the fresh-keeping cabinet. The motor is in the upper part. The outer part of the whole cylinder is almost immersed in the lubricating oil. The cylindrical piston is installed in the cylinder and is placed on the eccentric shaft. Eccentric turn, eccentric axis. For the shaft to drive the piston in the cylinder along the cylinder wall surface of the cylinder wall has a through slot, the slot is equipped with a slider, the slider and the rotor fit in the slot sliding, under the action of the spring force and the rolling rotor outer wall surface The dynamic seal is formed by contact, and the crescent-shaped space between the rolling rotor and the cylinder wall is divided into a helium chamber and a compression chamber. During the process of rotating the eccentric shaft around the center of the cylinder, the helium chamber completes the intake process, and the compression chamber completes the compression. And the exhaust process.
