Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | 4V420-15 |
Minimum Order Quantity: | 100PCS |
---|---|
Price: | Negotiation |
Packaging Details: | inner boxes,cartons,pallets |
Delivery Time: | 7 to 14 working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 100000 pcs per month |
Port Size: | In=Out=Exhaust=1/2'' | Valve Type: | Double Solenoid 5 Port 2 Position |
---|---|---|---|
Voltage: | 220VAC 110VAC 24VDC 12VDC | Connector: | Terminal & Grommet |
Working Pressure: | 0.15 To 0.8MPa(21-114psi) | Temperature: | -20 To +70℃ |
Max. Frequency: | 5 Cycle/sec | Body Material: | Aluminum Alloy |
Fluid: | Air (to Be Filtered By 40 μm Filter Element) | Application: | Automation |
High Light: | 4V420-15 Pneumatic Solenoid Valve,Directional Control Pneumatic Solenoid Valve,4V420-15 Air Control Valve |
4V420-15 1/2'' Directional Control Pneumatic Solenoid Valve
Other industry terms for pneumatic solenoid valves are solenoid air valves, direct action solenoid valves, direct operation solenoid valves, direct air pilot solenoid valves, solenoid operation direction control valves, direction control solenoid valves, universal solenoid valves, two-way solenoid valves, three-way solenoid valves and four-way solenoid valves.
Pneumatic solenoid valves are used to direct or stop the flow of compressed air to the equipment. They can be used for example to drive cylinders, larger industrial valves or pneumatic tools. Directional control valves are usually classified by two numbers, the first number indicating the number of ports and the second number indicating the number of states. The most common types are 3/2, 5/2, and 5/3. Valves can be single-acting or double-acting (one or two solenoid valves). Different operating voltages can be obtained by replacing the electromagnetic coils. Several models are available for manifold installation, please note the platform dimensions when selecting valves and manifes. Optionally, the valve body has the Namur configuration to install the valve directly onto the actuator.
5/2 Way Single Coil Pneumatic Solenoid Valve:4V110-06, 4V110-08, 4V210-06, 4V210-08, 4V310-08, 4V310-10, 4V410-15
5/2 Way Double Coil Pneumatic Solenoid Valve:4V120-06, 4V120-08, 4V220-06, 4V220-08, 4V320-08, 4V320-10, 4V420-15
5/3 Way Double Coil Pneumatic Solenoid Valve:4V130C-06, 4V130C-08, 4V230C-06, 4V230C-08, 4V330C-08, 4V330C-10, 4V430C-15
Technical Data:
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
||||
Acting
|
Internal pilot or external pilot
|
||||
Port Size
|
In=Out=Exhaust=1/2''
|
||||
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
Valve Type
|
5 port 2 position
|
5 port 3 position
|
|||
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
||||
Proof
|
1.5MPa (215psi)
|
||||
Temperature ℃
|
-20 to 70
|
||||
Material of Body
|
Aluminum alloy
|
||||
Max. frequency
|
3cycle/sec
|
Dimension Diagram:
4V420(Grommet)
4V420(Terminal)
Brando Supply:
1.Solenoid Valve:
Pulse Jet Valve: Goyen Type Pulse Jet Valve, SBFEC Type Pulse Jet Valve, ASCO Type Pulse Jet Valve , Turbo Type Pulse Jet Valve.
Direct Acting Solenoid Valve:Brass Solenoid Valve, Stainless Steel Solenoid Valve, Plastic Solenoid Valve and etc.
Refrigeration Solenoid Valve:Castel Type Solenoid Valve, Danfoss Type Solenoid Valve.
2.Repair Kit:Solenoid Coil, Solenoid Armature/Stem, Diaphragm Repair Kit and etc.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
